Siemens LME7 Series Technical Instructions

LME Series
Technical Instructions
LME-1000
PW Level Default Range Description
LEGEND - Password Level: S = Service; O = OEM; S/O = View - Service, Write - OEM; Info = Info Menu; Ser = Service Menu
Shaded Parameters = Frequently Used
Parameter Name
Parameter
Number
PME71.
111A1
PME71.
112A1
PME71.
901A1
701-711 Fault History Ser
Shows the current status (fault) along with the 10 most recent faults. 701 = current status, 702 = most
recent fault, 703 = next most recent fault, etc. Each fault has indices that provide additional information
about the fault:
Index 00 = fault code
Index 01 = start number
Index 02 = phase
Index 03 = load
• • •
920 Target Speed %
Displays the real time target speed of the PWM blower as a percentage of the maximum blower speed
(parameter 519). Will always display as a "-" on PME71.111A1 and PME71.112A1.
• • •
936 Actual Speed %
Displays the real time actual speed of the PWM blower as a percentage of the maximum blower speed
(parameter 519). Will always display as a "-" on PME71.111A1 and PME71.112A1.
• • •
951 Incoming Voltage Displays the real time mains voltage. Measured at terminal X3-04 pin 4 (neutral) and pin 5 (line).
• • •
954 Flame Signal
Displays the raw flame signal from 0-100% for any flame scanner type. A flame failure occurs when the
flame signal drops below 20% for the time period specified by parameter 254. This signal refers to input
terminal X10-06 (UV scanners) or input terminal X10-05.2 (flame rods).
• • •
Read only
700 Level: Fault History
900 Level: Operational Data
Read onlySer
