Siemens LME7 Series Technical Instructions

LME Series
Technical Instructions
LME-1000
PW Level Default Range Description
Parameter
Number
PME75.
811A1
PME75.
812A1
LEGEND - Password Level: S = Service; O = OEM; S/O = View - Service, Write - OEM; Info = Info Menu; Ser = Service Menu
Shaded Parameters = Frequently Used
Parameter Name
515.00 Actuator Purge Position S
Determines the position of the actuator during prepurge and postpurge. Cannot be changed on the
LME75. The actuator will always purge at high fire.
• •
515.01 Actuator Activation S/O 1 0-1
Used to activate or deactivate the use of an actuator. If set to 0, parameter 560 must also be set to 0.
0 = deactivated (no actuator)
1 = activated (with actuator)
• •
560 Analog Input Type S 2 0-2
Sets the type of input being used to control the actuator.
0 = no actuator / 3-position input
1 = not used
2 = analog input
• •
654 Analog Input Signal S 1 0-5
Sets the type of input signal being connected to terminal X65 or X5-03 when parameter 560 is set to 2.
This input signal is used to determine the actuator position during operation.
0 = 3-position
1 = 0-10 VDC
2 = 0-135 Ohm
3 = 0-20 mA
4 = 4-20 mA with lockout when input is less than 4 mA
5 = 4-20 mA without lockout when input is less than 4 mA
• •
701-711 Fault History Ser
Shows the current status (fault) along with the 10 most recent faults. 701 = current status, 702 = most
recent fault, 703 = next most recent fault, etc. Each fault has indices that provide additional information
about the fault:
Index 00 = fault code
Index 01 = start number
Index 02 = phase
Index 03 = load
• •
920 Target Speed % Not used on the LME75. Will always display as a "-".
• •
935 Actual Speed RPM Not used on the LME75. Will always display as a "-".
• •
936 Actual Speed % Not used on the LME75. Will always display as a "-".
• •
951 Incoming Voltage Displays the real time mains voltage. Measured at terminal X3-04 pin 4 (neutral) and pin 5 (line).
• •
954 Flame Signal
Displays the raw flame signal from 0-100% for any flame scanner type. A flame failure occurs when the
flame signal drops below 20% for the time period specified by parameter 217.01.
Index 00 = flame rod (input X10-06.2)
Index 01 = flame scanner QRA75/QRI (input X10-05.1)
• •
Read onlySer
Read only
700 Level: Fault History
900 Level: Operational Data
600 Level: Analog Input Configuration
500 Level: Actuator Configuration
Read only
SCC Inc. Page 7 Section 4
