Siemens Midimaster Eco - Page 127

ECO REFERENCE MANUAL
14-2
D-R
208/240V MICROMASTER Eco:
Screened cable
F
max
= 16kHz (Switching Frequency)
Current (I/I
N
) ECO1-75/2 ECO1-110/2 ECO1-150/2 ECO1-220/2 ECO1-300/2 ECO1-400/2
Cable length (m)
1.5
185 200 200 155 150 145
1.4
200 200 200 200 200 200
1.3
200 200 200 200 200 200
1.2
200 200 200 200 200 200
1.1
200 200 200 200 200 200
1.0
200 200 200 200 200 200
380V/500V MICROMASTER Eco:
Un-screened cable
F
max
= 4kHz (Switching Frequency)
Current
(I/I
N
)
ECO1-110/3 ECO1-150/3 ECO1-220/3 ECO1-300/3 ECO1-400/3 ECO1-550/3 ECO1-750/3
Cable Length (m)
440V 550V 440V 550V 440V 550V 440V 550V 440V 550V 440V 550V 440V 550V
1.5
110 100 110 100 170 165 165 160 200 200 200 200 200 200
1.4
120 110 120 110 175 170 170 165 200 200 200 200 200 200
1.3
130 115 130 115 175 170 170 165 200 200 200 200 200 200
1.2
140 120 140 120 175 170 170 165 200 200 200 200 200 200
1.1
150 130 150 130 175 170 170 165 200 200 200 200 200 200
1.0
160 140 160 140 175 170 170 165 200 200 200 200 200 200
380V/500V MICROMASTER Eco:
Screened cable
F
max
= 4kHz (Switching Frequency)
Current
(I/I
N
)
ECO1-110/3 ECO1-150/3 ECO1-220/3 ECO1-300/3 ECO1-400/3 ECO1-550/3 ECO1-750/3
Cable Length (m)
440V 550V 440V 550V 440V 550V 440V 550V 440V 550V 440V 550V 440V 550V
1.5
80 70 80 70 140 140 135 135 200 200 200 200 200 200
1.4
85 80 85 80 145 145 140 140 200 200 200 200 200 200
1.3
95 80 95 80 145 145 140 140 200 200 200 200 200 200
1.2
100 80 100 80 145 145 140 140 200 200 200 200 200 200
1.1
100 80 100 80 145 145 140 140 200 200 200 200 200 200
1.0
100 80 100 80 145 145 140 140 200 200 200 200 200 200
