ECO REFERENCE MANUAL
14-3
D-R
MAXIMUM OUTPUT CURRENT AT ELEVATED TEMPERATURES - VARIABLE
TORQUE APPLICATIONS
Maximum Inverter Output Current With High Ambient Temperature - 25m of Screened Cable or
50m of Unscreened Cable Maximum, Variable Torque Applications (110% overload for 1 minute
in every 5 minutes)
40 deg C 50 deg C 60 deg C 70 deg C
Model Number 2kHz 4kHz 8kHz 16kHz 2kHz 4kHz 8kHz 16kHz 2kHz 4kHz 8kHz 16kHz 2kHz 4kHz 8kHz 16kHz
ECO1-550/2 @ 264V 22 22 16.5 8.8 22 22 16.5 8.6 22 22 16.5 8.6 20 17.3 16.5 8.6
ECO1-750/2 @ 264V 28.0 28.0 21 10.9 28 28 21 10.9 28 25.9 21 10.9 20 17.3 17.3 8.8
ECO1-1100/2 @ 264V 42.0 42.0 31.5 23.1 42 42 31.5 23.1 39.9 38.9 31.5 23.1 24.4 24.3 21.3 21.2
ECO1-1500/2 @ 264V 54 54 (a) (a) 49.7 49.7 (a) (a) 46.6 46.6 (a) (a) 37.3 35.4 (a) (a)
ECO1-1850/2 @ 264V 68.0 68.0 (a) (a) 52.8 52.8 (a) (a) 49.5 49.5 (a) (a) 39.6 37.5 (a) (a)
ECO1-2200/2 @ 264V 80.0 80.0 (a) (a) 62.1 62.1 (a) (a) 58.2 58.2 (a) (a) 46.6 44.1 (a) (a)
ECO1-3000/2 @ 264V 95.0 95.0 (a) (a) 73.7 73.7 (a) (a) 69.1 69.1 (a) (a) 55.3 52.4 (a) (a)
ECO1-3700/2 @ 264V 130.0 130.0 (a) (a) 130.0 130.0 (a) (a) 130.0 130.0 (a) (a) 129.2 119.9 (a) (a)
ECO1-4500/2 @ 264V 154.0 154.0 (a) (a) 154 154 (a) (a) 154 154 (a) (a) 153 142 (a) (a)
ECO1-1100/3 @ 460V 23.5 23.5 21.1 12.9 21.0 20.4 23.3 12.9 18.6 17.8 21.8 12.9 10.5 10.4 7.0 (b)
ECO1-1500/3 @ 460V 30.0 30.0 22.5 11.7 28.8 26 22.3 11.7 23.7 22.7 20.9 11.7 13.4 13.3 6.7 (b)
ECO1-1850/3 @ 460V 37.0 37.0 33.3 23.7 33.2 30.3 28.3 15.1 24.2 24.2 27.4 15.1 8.4 8.4 10.8 10.1
ECO1-2200/3 @ 460V 43.5 43.5 30 22 39 35.6 25.5 14 28.4 28.4 24.7 14 9.9 9.9 9.7 9.4
ECO1-3000/3 @ 460V 58.0 58.0 (a) (a) 51.8 51.8 (a) (a) 35.9 35.9 (a) (a) (b) (b) (a) (a)
ECO1-3700/3 @ 460V 71.0 71.0 (a) (a) 63.4 63.4 (a) (a) 44.0 44.0 (a) (a) (b) (b) (a) (a)
ECO1-4500/3 @ 460V 84.0 84.0 (a) (a) 75 75 (a) (a) 52 52 (a) (a) (b) (b) (a) (a)
ECO1-5500/3 @ 460V 102.0 102.0 (a) (a) 102.0 100.8 (a) (a) 102.0 91.7 (a) (a) 93.5 82.6 (a) (a)
ECO1-7500/3 @ 460V 138.0 138.0 (a) (a) 138.0 136.4 (a) (a) 138.0 124.0 (a) (a) 126.5 111.7 (a) (a)
ECO1-9000/3 @ 460V 168.0 168.0 (a) (a) 168 166 (a) (a) 168 151 (a) (a) 154 136 (a) (a)
ECO1-110K/3 @ 460V 210 193 (a) (a) 157 145 (a) (a) (b) (b) (a) (a) (b) (b) (a) (a)
ECO1-132K/3 @ 460V 260 239 (a) (a) 195 179 (a) (a) (b) (b) (a) (a) (b) (b) (a) (a)
ECO1-160K/3 @ 460V 315 290 (a) (a) 236 217 (a) (a) (b) (b) (a) (a) (b) (b) (a) (a)
ECO1-200K/3 @ 460V 370 340 (a) (a) 277 255 (a) (a) (b) (b) (a) (a) (b) (b) (a) (a)
ECO1-250K/3 @ 460V 510 469 (a) (a) 382 352 (a) (a) (b) (b) (a) (a) (b) (b) (a) (a)
ECO1-315K/3 @ 460V 590 (a) (a) (a) 442 (a) (a) (a) (b) (a) (a) (a) (b) (a) (a) (a)
ECO1-1100/3 @ 550V 21.1 21.1 21.1 11.6 20.3 18.9 21.1 (b) 16.3 14.8 19.5 (b) (b) (b) (b) (b)
ECO1-1500/3 @ 550V 27.0 27.0 19.5 8.7 26 24.2 19.5 20.9 18.9 18 (b) (b) (b) (b) (b)
ECO1-1850/3 @ 550V 33.3 33.3 30 21.3 29.8 28.8 22.5 13.6 22.7 17.9 10.2 10.0 12.1 (b) (b) (b)
ECO1-2200/3 @ 550V 39.1 39.1 28.3 19.6 35 33.8 21.2 12.5 26.7 21 9.6 9.2 14.2 (b) (b) (b)
ECO1-3000/3 @ 550V 52.2 52.2 (a) (a) 44.2 44.2 (a) (a) 31.1 31.1 (a) (a) (b) (b) (a) (a)
ECO1-3700/3 @ 550V 63.9 63.9 (a) (a) 54.1 54.1 (a) (a) 38.0 38.0 (a) (a) (b) (b) (a) (a)
ECO1-4500/3 @ 550V 75.6 75.6 (a) (a) 64 64 (a) (a) 45 45 (a) (a) (b) (b) (a) (a)
ECO1-5500/3 @ 550V 91.8 91.8 (a) (a) 91.8 91.8 (a) (a) 91.8 88.6 (a) (a) 89.9 79.5 (a) (a)
ECO1-7500/3 @ 550V 124.2 124.2 (a) (a) 124.2 124.2 (a) (a) 124.2 119.9 (a) (a) 121.6 107.6 (a) (a)
ECO1-9000/3 @ 550V 151.2 151.2 (a) (a) 151.2` 151.2 (a) (a) 151.2 146 (a) (a) 148 131 (a) (a)
ECO1-400/4 @ 660V 6.1 6.1 6.1 6.1
ECO1-550/4 @ 660V 9.0 9.0 9.0 8.2
ECO1-750/4 @ 660V 11.0 11.0 11.0 8.2
ECO1-1100/4 @ 660V 17.0 17.9 17.0 9.3
ECO1-1500/4 @ 660V 22.0 22.0 16.5 8.6
ECO1-1850/4 @ 660V 27.0 27.0 24.3 17.3
ECO1-2200/4 @ 660V 32.0 32.0 24.0 17.6
ECO1-3000/4 @ 660V 41.0 41.0 (a) (a) 41.0 41.0 (a) (a) 36.2 36.2 (a) (a) 22.6 22.6 (a) (a)
ECO1-3700/4 @ 660V 52.0 52.0 (a) (a) 52.0 52.0 (a) (a) 46.0 46.0 (a) (a) 28.6 28.6 (a) (a)
ECO1-4500/4 @ 660V 62.0 62.0 (a) (a) 62 62 (a) (a) 54.8 54.8 (a) (a) 34.1 34.1 (a) (a)
Notes: (a) Switching frequency not available
(b) Not Possible.
