ECO REFERENCE MANUAL
5-2
TECHNICAL FEATURES
Inverter MICROMASTER Eco MIDIMASTER Eco
Input Voltage 3 AC 208 - 240V±10%
3 AC 380 – 480 / 500V±10%
3 AC 208 - 240V±10%
3 AC 380V - 460 / 480 / 500V±10%
3 AC 525V - 575V±15%
Power Ranges
3 AC 208-240V
3 AC 380-500V
3 AC 525-575V
0.75kW - 4.0kW
1.1kW - 7.5kW
-
5.5kW - 45kW (1.1kW - 45kW) IP56
11kW - 315kW (3kW - 90kW) IP56
4kW - 45kW (4kW - 45kW) IP56
Protection Level IP20 / NEMA1 IP20 / IP21 / NEMA1 or IP56 / NEMA 4/12
or
IP20 / NEMA1 with integrated Class A
EMC filter
EMC conformance
EN55011 Class A
3 AC 208-240V
3 AC 380-460V
3 AC 525-575V
Footprint Filter
Integrated or Footprint Filter
not available
Integrated or external Filter
Integrated or external Filter
not available
EMC conformance
EN55011 Class B
3 AC 208-240V
3 AC 380-460V
3 AC 525-575V
Footprint Filter
Footprint Filter
not available
External Filter
External Filter
not available
Temperature
Range
0 - 50
0
C0 - 40
0
C See Section 14 for derating at
higher temperatures
Control Method Energy Control Optimisation (Eco) Mode or Multi-motor Mode.
Protection Features Undervoltage, Overvoltage, Overload, Short-Circuit, Earth Fault, Motor Pull-
out, Motor Overtemperature, Drive Overtemperature
Maximum Motor
Cable Length
See section 14 See Section 14
Overload Capability 150% for 60 sec 110% for 60 sec
Digital Inputs 6 configurable 6 configurable
Fixed Frequencies 8 8
Relay Outputs 2 configurable (230V AC/1.0A) 2 configurable (230V AC/1.0A)
Analogue Inputs 2 2
Analogue Outputs 1 configurable 2 configurable
Serial Interface RS485
Dynamic Braking Compound Braking
/DC Injection Braking
Compound Braking
/DC Injection Braking
Process Control PID PID
