ECO REFERENCE MANUAL
14-5
D-R
MAXIMUM OUTPUT CURRENT WITH LONG SCREENED CABLES - VARIABLE
TORQUE APPLICATIONS
Maximum Inverter Output With Current Long Screened Cable Lengths - 40°C Ambient
Temperature Maximum, Variable Torque Applications (110% overload for 1 minute in every 5
minutes)
up to 50m up to 100m up to 200m up to 300m
Model Number 2kHz 4kHz 8kHz 16kHz 2kHz 4kHz 8kHz 16kHz 2kHz 4kHz 8kHz 16kHz 2kHz 4kHz 8kHz 16kHz
ECO1-550/2 @ 264V 22.0 22.0 16.5 8.6 21.4 21.0 16.5 8.6 20.2 19.8 16.5 8.6 19.3 18.7 16.5 8.6
ECO1-750/2 @ 264V 28.0 28.0 21 10.9 28.0 28.0 21.0 10.9 28.0 27.9 21.0 10.9 27.9 27.9 21.0 10.9
ECO1-1100/2 @ 264V 42.0 42.0 37.8 26.9 42.0 42.0 37.8 26.9 42.0 41.7 37.8 26.9 41.3 40.8 37.8 26.9
ECO1-1500/2 @ 264V 54.0 54.0 (a) (a) 54.0 54.0 (a) (a) 54.0 54.0 (a) (a) 54.0 54.0 (a) (a)
ECO1-1850/2 @ 264V 68.0 68.0 (a) (a) 57.3 57.3 (a) (a) 57.3 57.3 (a) (a) 57.3 57.3 (a) (a)
ECO1-2200/2 @ 264V 80.0 80.0 (a) (a) 67.4 67.4 (a) (a) 67.4 67.4 (a) (a) 67.4 67.4 (a) (a)
ECO1-3000/2 @ 264V 104.0 104.0 (a) (a) 104.0 104.0 (a) (a) 104.0 104.0 (a) (a) 104.0 104.0 (a) (a)
ECO1-3700/2 @ 264V 130.0 130.0 (a) (a) 130.0 130.0 (a) (a) 130.0 130.0 (a) (a) 130.0 130.0 (a) (a)
ECO1-4500/2 @ 264V 154.0 154.0 (a) (a) 154.0 154.0 (a) (a) 154.0 154.0 (a) (a) 154.0 154.0 (a) (a)
ECO1-1100/3 @ 460V 23.5 23.5 23.5 12.9 21.6 20.5 20.4 (b) 21.2 19.6 20.2 (b) 20.8 18.6 (b) (b)
ECO1-1500/3 @ 460V 30.0 30.0 22.5 11.7 27.6 26.2 19.5 (b) 27.1 25.0 19.3 (b) 26.6 23.8 (b) (b)
ECO1-1850/3 @ 460V 37.0 37.0 33.3 23.7 34.0 32.4 28.1 14.5 33.3 31.0 27.8 13.1 32.4 29.8 27.4 11.6
ECO1-2200/3 @ 460V 43.5 43.5 30 22 40.0 38.1 25.3 13.5 39.1 36.5 25.0 12.2 38.1 35.0 24.7 10.8
ECO1-3000/3 @ 460V 58.0 58.0 (a) (a) 55.2 55.2 (a) (a) 55.2 55.2 (a) (a) (b) (b) (a) (a)
ECO1-3700/3 @ 460V 71.0 71.0 (a) (a) 67.6 67.6 (a) (a) 67.6 67.5 (a) (a) (b) (b) (a) (a)
ECO1-4500/3 @ 460V 84.0 84.0 (a) (a) 80.0 80.0 (a) (a) 80.0 79.9 (a) (a) 79.9 79.8 (a) (a)
ECO1-5500/3 @ 460V 102.0 102.0 (a) (a) 102.0 102.0 (a) (a) 102.0 102.0 (a) (a) 102.0 101.9 (a) (a)
ECO1-7500/3 @ 460V 138.0 138.0 (a) (a) 138.0 138.0 (a) (a) 138.0 138.0 (a) (a) 138.0 137.9 (a) (a)
ECO1-9000/3 @ 460V 168.0 168.0 (a) (a) 168.0 168.0 (a) (a) 168.0 168.0 (a) (a) 168.0 167.9 (a) (a)
ECO1-110K/3 @ 460V 210 210 (a) (a) 210 210 (a) (a) 210 210 (a) (a) 210 200 (a) (a)
ECO1-132K/3 @ 460V 260 260 (a) (a) 260 260 (a) (a) 260 260 (a) (a) 260 247 (a) (a)
ECO1-160K/3 @ 460V 315 315 (a) (a) 315 315 (a) (a) 315 315 (a) (a) 315 300 (a) (a)
ECO1-200K/3 @ 460V 370 370 (a) (a) 370 370 (a) (a) 370 370 (a) (a) 370 352 (a) (a)
ECO1-250K/3 @ 460V 510 510 (a) (a) 510 510 (a) (a) 510 510 (a) (a) 510 485 (a) (a)
ECO1-315K/3 @ 460V 590 (a) (a) (a) 590 (a) (a) (a) 590 (a) (a) (a) 590 (a) (a) (a)
ECO1-1100/3 @ 550V 21.1 21.1 21.1 11.6 20.2 18.8 18.7 (b) 20.2 17.0 (b) (b) (b) (b) (b) (b)
ECO1-1500/3 @ 550V 27.0 27.0 19.5 8.7 25.9 24.1 17.3 (b) 25.8 21.7 (b) (b) 25.3 19.0 (b) (b)
ECO1-1850/3 @ 550V 33.3 33.3 30 21.3 32.3 30.4 26.7 14.1 31.4 28.3 23.4 (b) 30.3 (b) (b) (b)
ECO1-2200/3 @ 550V 39.1 39.1 28.3 19.6 37.9 35.7 25.2 13.0 36.9 33.2 22.1 (b) 35.6 30.9 13.8 (b)
ECO1-3000/3 @ 550V 52.2 52.2 (a) (a) 52.2 52.2 (a) (a) 52.2 52.2 (a) (a) (b) (b) (a) (a)
ECO1-3700/3 @ 550V 63.9 63.9 (a) (a) 63.9 63.9 (a) (a) 63.9 63.9 (a) (a) (b) (b) (a) (a)
ECO1-4500/3 @ 550V 75.6 75.6 (a) (a) 75.6 75.6 (a) (a) 75.6 75.6 (a) (a) 75.6 75.6 (a) (a)
ECO1-5500/3 @ 550V 91.8 91.8 (a) (a) 91.8 91.8 (a) (a) 91.8 91.8 (a) (a) 91.8 91.8 (a) (a)
ECO1-7500/3 @ 550V 124.2 124.2 (a) (a) 124.2 124.2 (a) (a) 124.2 124.2 (a) (a) 124.2 124.2 (a) (a)
ECO1-9000/3 @ 550V 151.2 151.2 (a) (a) 151.2` 151.2 (a) (a) 151.2 151.2 (a) (a) 151.2 151.2 (a) (a)
ECO1-400/4 @ 660V 6.1 6.1 6.1 6.1
ECO1-550/4 @ 660V 9.0 9.0 9.0 8.2
ECO1-750/4 @ 660V 11.0 11.0 11.0 8.2
ECO1-1100/4 @ 660V 17.0 17.0 17.0 9.3
ECO1-1500/4 @ 660V 22.0 22.0 16.5 8.6
ECO1-1850/4 @ 660V 27.0 27.0 24.3 17.3
ECO1-2200/4 @ 660V 32.0 32.0 24.0 17.6
ECO1-3000/4 @ 660V 41.0 41.0 (a) (a) 40.9 40.9 (a) (a) 40.9 40.8 (a) (a) 40.9 40.7 (a) (a)
ECO1-3700/4 @ 660V 52.0 52.0 (a) (a) 51.9 51.9 (a) (a) 51.9 51.7 (a) (a) 51.8 51.7 (a) (a)
ECO1-4500/4 @ 660V 62.0 62.0 (a) (a) 61.9 61.9 (a) (a) 61.9 61.7 (a) (a) 61.8 61.6 (a) (a)
Notes: (a) Switching frequency not available
(b) Not Possible.
