ECO REFERENCE MANUAL
15-6
Model/Type Maximum
Variable Torque
Continuous
Input Current (A)
Frame
Size
EMC Input Filter
Class A
Order Code
EMC Input Filter
Class B
Order Code
380-500V +/-
10% 3ac
380-460V +/-10% 3ac 380-460V +/-10% 3ac
ECO1-110/3 4.9 A 6SE3290-0DA87-0FA1 6SE3290-0DA87-0FB1
ECO1-150/3 5.9 A 6SE3290-0DA87-0FA1 6SE3290-0DA87-0FB1
ECO1-220/3 8.8 B 6SE3290-0DB87-0FA3 6SE3290-0DB87-0FB3
ECO1-300/3 11.1 B 6SE3290-0DB87-0FA3 6SE3290-0DB87-0FB3
ECO1-400/3 13.6 C 6SE3290-0DC87-0FA4 6SE3290-0DC87-0FB4
ECO1-550/3 17.1 C 6SE3290-0DC87-0FA4 6SE3290-0DC87-0FB4
ECO1-750/3 22.1 C 6SE3290-0DC87-0FA4 6SE3290-0DC87-0FB4
ECO1-1100/3 30 4 6SE3290-0DG87-0FA5 6SE2100-1FC20
ECO1-1500/3 32 4 6SE3290-0DG87-0FA5 6SE2100-1FC20
ECO1-1850/3 41 5 6SE3290-0DH87-0FA5 6SE2100-1FC20
ECO1-2200/3 49 5 6SE3290-0DH87-0FA5 6SE2100-1FC20
ECO1-3000/3 64 6 6SE3290-0DJ87-0FA6 6SE2100-1FC21
ECO1-3700/3 79 6 6SE3290-0DJ87-0FA6 6SE2100-1FC21
ECO1-4500/3 96 6 6SE3290-0DJ87-0FA6 6SE3290-0DK87-0FB7
ECO1-5500/3 113 7 6SE3290-0DK87-0FA7 6SE3290-0DK87-0FB7
ECO1-7500/3 152 7 6SE3290-0DK87-0FA7 6SE3290-0DK87-0FB7
ECO1-9000/3 185 7 6SE3290-0DK87-0FA7 6SE3290-0DK87-0FB7
ECO1-110K/3 210 8 6SE7033-2ES87-0FA1 not available
ECO1-132K/3 260 8 6SE7033-2ES87-0FA1 not available
ECO1-160K/3 315 8 6SE7033-2ES87-0FA1 not available
ECO1-200K/3 370 8 6SE7036-0ES87-0FA1 not available
ECO1-250K/3 510 9 6SE7036-0ES87-0FA1 not available
ECO1-315K/3 590 9 6SE7036-0ES87-0FA1 not available
525-575V +/-
15% 3ac
ECO1-400/4 7 4 not available not available
ECO1-550/4 10 4 not available not available
ECO1-750/4 12 4 not available not available
ECO1-1100/4 18 4 not available not available
ECO1-1500/4 24
4 not available not available
ECO1-1850/4 29
5 not available not available
ECO1-2200/4 34
5 not available not available
ECO1-3000/4 45
6 not available not available
ECO1-3700/4 55
6
not available not available
ECO1-4500/4 65
6 not available not available
