ECO REFERENCE MANUAL
15-21
Inverter Input Line Reactor (2%) Dimensions Weight
rated for low impedence supplies H x W x D
(mm) (kg)
ECO1-1500/3 4EP3700-2US (4EP3700-6US) 159x178x73 3.3
ECO1-1850/3 4EP3700-5US (4EP3700-1US) 159x178x73 3.8
ECO1-2200/3 4EP3800-2US (4EP3801-2US) 193x178x88 4
ECO1-3000/3 4EP3800-7US (4EP3900-1US) 153x178x88 (181x219x99) 5
ECO1-3700/3 4EP3900-2US (4EP4000-1US) 181x219x99 (181x219x119) 6.5
ECO1-4500/3 4EP4000-2US (4EP4000-8US) 181x219x119 8.2
ECO1-5500/3 4EP4000-6US (4EP4000-8US) 181x219x119 9.6
ECO1-7500/3 4EU2451-2UA00 (4EU2551-2UA00) 220x206x105 (220x206x128) 12
ECO1-9000/3 4EU2551-4UA00 (4EU2551-6UA00) 220x206x128 15.3
380V 50Hz- 480V 60Hz
ECO1-110K/3 4EU2551-8UA00 220x206x128 16.4
ECO1-132K/3 4EU2751-0UB00 250x235x146 22.8
ECO1-160K/3 4EU2751-7UA00 250x235x146 23
ECO1-200K/3 4EU2751-8UA00 250x235x146 26.8
ECO1-250K/3 4EU3051-5UA00 280x264x155 38.2
ECO1-315K/3 4EU3051-6UA00 280x264x155 40.3
525V- 575V 50/60Hz
ECO1-400/4 4EP3400-3US 122x124x73 1.3
ECO1-550/4 4EP3600-8US 139x148x78 2.3
ECO1-750/4 4EP3600-2US 139x148x78 2.5
ECO1-1100/4 4EP3600-3US 139x148x78 2.4
ECO1-1500/4 4EP3700-6US 159x178x73 3.4
ECO1-1850/4 4EP3700-1US 159x178x73 3.7
ECO1-2200/4 4EP3801-2US 193x178x88 4.2
ECO1-3000/4 4EP3800-1US 193x178x88 4.6
ECO1-3700/4 4EP3900-1US 181x219x99 6.4
ECO1-4500/4 4EP4000-7US 181x219x119 7.7
