ECO REFERENCE MANUAL
17-2
Select Display via
Parameter 001
in the Expert
Parameter Mode.
Display frequency.
Parameter 001
0 = Output frequency
Display motor current.
Parameter 001
2 = Motor current
Display motor speed.
Parameter 001
5 = Motor speed (RPM)
Displa
y
Parameters
Ramp-up time.
Parameter 002
0 -150 sec
Ramp-down time.
Parameter 003
0 -150 sec
Digit. freq. setpoint.
Parameter 006
0=manual setpoint
1=analog / 2=digital setup
Hand/Auto.
Parameter 007
0 = Hand
1 = Auto
Minimum motor freq.
Parameter 012
0 - 150 Hz
Maximum motor freq.
Parameter 013
0 - 150 Hz
Start on the Fly.
Parameter 016
0=disable 2=enable
Nominal rating plate
frequency for motor.
Parameter 081
0 - 150 Hz
Nominal rating plate
speed for motor.
Parameter 082
0-9999 U/min
Nominal rating plate
current for motor.
Parameter 083
0,1 - 300A
Nominal rating plate
voltage for motor.
Parameter 084
0 - 1000V
Nominal rating plate
power for motor.
Parameter 085
0,12 - 250 kW
Enable Expert para.
Parameter 199
0=Basic parameter
1=Expert parameter
Basic Parameters
Automatic restart
after mains failure.
Parameter 015
0=display / 1=enable
Automatic restart after
fault.
Parameter 018
0=disable / 1=enable
Analogue input.
Parameter 023
0 = 0-10V / 0-20mA
1 = 2-10V / 4-20mA
Skip frequency.
Para 027/028/029
0 - 150 Hz
Input terminal function.
Parameter 051-056
see table
Selection relay output.
Parameter 061 & 062
see table
DC injection braking.
Parameter 073
0 - 200%
Pulse frequency.
Parameter 076
see table
Motor current limit.
Parameter 086
0 - 200%
See Section 13 of
Reference Manual for
more Expert Parameters
Expert Parameters
Commisionin
g
MICROMASTER Eco
