ECO REFERENCE MANUAL
5-7
MIDIMASTER Eco - IP56 / NEMA4/12 / with Integral Class A Filter, 3ph 208- 240 V ±10%
Product Rated Inverter
Output Current
Motor Rating H x W x D Weight Order No.
(A) (kW) (HP) (mm) (kg)
ECO1-110/2 5.5 1.1 1.5 675x360x351
34
6SE9515-5CS55
ECO1-150/2 7.4 1.5 2.0 675x360x351
34
6SE9517-4CS55
ECO1-220/2 10.4 2.2 3.0 675x360x351
34
6SE9521-0CS55
ECO1-300/2 13.6 3.0 4.0 675x360x351
34
6SE9521-4CS55
ECO1-400/2 17.5 4.0 5.0 675x360x351
34
6SE9521-8CS55
ECO1-550/2 23 5.5 7.5 675x360x351
34
6SE9522-3CS55
ECO1-750/2 28 7.5 10 675x360x351
34
6SE9522-8CS55
ECO1-1100/2 42 11 15 775x360x422
43
6SE9524-2CS55
ECO1-1500/2 54 15 20 875x360x483
58
6SE9525-4CS55
ECO1-1850/2 68 18.5 25 875x360x783
61
6SE9526-8CS55
ECO1-2200/2 80 22 30 875x360x783
62
6SE9528-0CS55
ECO1-3000/2 104 30 40 1150x500x570
105
6SE9531-0CS55
ECO1-3700/2 130 37 50 1150x500x570
106
6SE9531-3CS55
ECO1-4500/2 154 45 60 1150x500x570
107
6SE9531-5CS55
MIDIMASTER Eco - IP56 (NEMA 4/12) 3ph 380 -500 V ±10%
Product Rated Inverter Output
Current
Motor Rating H x W x D Weight Order No.
400V [500V] (A) (kW) (HP) (mm) (kg)
ECO1-300/3 7.7 [6.9] 3 4 675x360x351 29 6SE9517-7DS45
ECO1-400/3 10.2 [9.1] 4 5 675x360x351 29 6SE9521-0DS45
ECO1-550/3 13.2 [11.8] 5.5 7.5 675x360x351 29 6SE9521-3DS45
ECO1-750/3 17 [15.2] 7.5 10 675x360x351 29 6SE9521-7DS45
ECO1-1100/3 23.5 [21] 11 15 675x360x351 29 6SE9522-4DS45
ECO1-1500/3 30 [27] 15 20 675x360x351 30 6SE9523-0DS45
ECO1-1850/3 37 [34] 18.5 25 775x360x422 39 6SE9523-7DS45
ECO1-2200/3 43.5 [40] 22 30 775x360x422 40 6SE9524-3DS45
ECO1-3000/3 58 [52] 30 40 875x360x483 50 6SE9525-8DS45
ECO1-3700/3 71 [65] 37 50 875x360x483 52 6SE9527-1DS45
ECO1-4500/3 84 [77] 45 60 875x360x483 54 6SE9528-4DS45
ECO1-5500/3 102 [96] 55 75 1150x500x570 97 6SE9531-0DS45
ECO1-7500/3 138 [124] 75 100 1150x500x570 99 6SE9531-4DS45
ECO1-9000/3 168 [152] 90 125 1150x500x570 100 6SE9531-7DS45
