Milltronics MFA 4p
Operating Instructions, 08/2017, A5E33988839_AB
25
Troubleshooting
6
6.1
Troubleshooting
LED 1
LED 2
Term 7/8
(note 1)
C8
Term 1/2
relay 1 out
Term 4/5
relay 2 out
Normal pulsing on 24 V 27 V closed closed
Alarm
pulsing
off
24 V
27 V
open
open
Probe reversed
polarity
on off 20 V 27 V open open
Probe wiring
open circuit
off off 27 V 27 V open open
Probe wiring
short circuit
off off 0 V 27 V open open
Relay defective
pulsing
on
24 V
27 V
open
open
