Siemens MJ-4 Series Installation Manual

30
104 SF= 10 Vsource 6th harmonic, RMS
105 SF= 10 Vsource 7th harmonic, RMS
106 SF= 10 Vsource 8th harmonic, RMS
107 SF= 10 Vsource 9th harmonic, RMS
108 SF= 10 Vsource 10th harmonic, RMS
109 SF= 10 Vsource 11th harmonic, RMS
110 SF= 10 Vsource 12th harmonic, RMS
111 SF= 10 Vsource 13th harmonic, RMS
112 SF= 10 Vsource 14th harmonic, RMS
113 SF= 10 Vsource 15th harmonic, RMS
114 SF= 10 Vsource 16th harmonic, RMS
115 SF= 10 Vsource 17th harmonic, RMS
116 SF= 10 Vsource 18th harmonic, RMS
117 SF= 10 Vsource 19th harmonic, RMS
118 SF= 10 Vsource 20th harmonic, RMS
119 SF= 10 Vsource 21st harmonic, RMS
120 SF= 10 Vsource 22nd harmonic, RMS
121 SF= 10 Vsource 23rd harmonic, RMS
122 SF= 10 Vsource 24th harmonic, RMS
123 SF= 10 Vsource 25th harmonic, RMS
124 SF= 10 Vsource 26th harmonic, RMS
125 SF= 10 Vsource 27th harmonic, RMS
126 SF= 10 Vsource 28th harmonic, RMS
127 SF= 10 Vsource 29th harmonic, RMS
128 SF= 10 Vsource 30th harmonic, RMS
129 SF= 10 Vsource 31st harmonic, RMS
130 SF = 1 MJ-X Main Proc. SW Version
131 SF = 1 Number of Resets
132 SF=10 Compensated Voltage (Secondary)
133 SF=10 Line Frequency
134 SF=10 Percent Regulation
135 SF=10 % Voltage Reduction in Effect
136 SF = 1 Number of Interval Logs Stored
137 SF=1000 Vld Total Harm. Distortion (%)
138 SF = 10 Vload Harmonics RMS value
139 SF=1000 Iload Total Harm. Distortion (%)
140 SF = 10 Iload Harmonics RMS value
141 SF=1000 Vsrc Total Harm. Distortion (%)
142 SF = 10 Vsource Harmonics RMS value
143 SF = 1 VRC Status
144 SF = 1 VLC Status
145 SF = 1 Auto Tap Command Status
146 SF = 1 Band Status
147 SF = 1 Tap Control Mode Status
148 SF = 1 R/A/M switch position
149 SF = 1 Alert Status
150 SF = 1 Time period for Interval Log (minutes)
151 SF = 1 Number of Event Logs Stored
152 SF = 1 MJX Reset Status Register
153 Diagnostics Results Register 1
154 Diagnostics Results Register 2
155 SF = 1 Previous Month Ops Count
156 SF = 1 MP Board Hardware version
157 SF = 1 Power Board HW version
158 SF = 1 MP HC16 Mask version
159 SF = 1 Elapsed Operations Count
160 SF = 1 Year-To-Date Ops Count
161 SF = 1 KWHR Forward
162 SF = 1 KVARHR fwd lead
