Siemens MJ-4 Series Installation Manual

MJ-4 Communications Module
31
163 SF = 1 KVARHR fwd lag
164 SF = 1 KWHR Reverse
165 SF = 1 KVARHR rev lead
166 SF = 1 KVARHR rev lag
167 SF = 1 Operations Count for last 24 hours
168 SF = 1 Operations Count for last 30 days
169 SF = 1 Month-To-Date Operations Count
170 SF = 100 PF at Min. kVA Dmd (Fwd)
171 SF = 100 PF at Max. kVA Dmd (Fwd)
172 SF = 100 PF at Min. kVA Dmd (Rev)
173 SF = 100 PF at Max. kVA Dmd (Rev)
174 variable Load Current Dmd (Fwd Min) (Amps)
175 variable Load Current Dmd (Fwd Max) (Amps)
176 SF =1 kVA Load Dmd (Fwd Min)
177 SF =1 kVA Load Dmd (Fwd Max)
178 SF =1 kVAR Load Dmd (Fwd Min)
179 SF =1 kVAR Load Dmd (Fwd Max)
180 SF =1 kW Load Dmd (Fwd Min)
181 SF =1 kW Load Dmd (Fwd Max)
182 SF = 10 Load Voltage Dmd (Fwd Min)
183 SF = 10 Load Voltage Dmd (Fwd Max)
184 SF = 10 Comp Voltage Dmd (Fwd Min) (Volts)
185 SF = 10 Comp Voltage Dmd (Fwd Max) (Volts)
186 variable Load Current Dmd (Rev Min) (Amps)
187 variable Load Current Dmd (Rev Max) (Amps)
188 SF = 1 kVA Load Dmd (Rev Min)
189 SF = 1 kVA Load Dmd (Rev Max)
190 SF = 1 kVAR Load Dmd (Rev Min)
191 SF = 1 kVAR Load Dmd (Rev Max)
192 SF = 1 kW Load Dmd (Rev Min)
193 SF = 1 kW Load Dmd (Rev Max)
194 SF = 10 Load Voltage Dmd (Rev Min) (Volts)
195 SF = 10 Load Voltage Dmd (Rev Max) (Volts)
196 SF = 10 Comp. Voltage Dmd (Rev Min) (Volts)
197 SF = 10 Comp. Voltage Dmd (Rev Max) (Volts)
198 SF = 10 Vsrc Dmd (Fwd Min)
199 SF = 10 Vsrc Dmd (Fwd Max)
200 SF = 10 Vsrc Dmd (Rev Min)
201 SF = 10 Vsrc Dmd (Rev Max)
202 SF = 10 Load Voltage Inst. Fwd Min
203 SF = 10 Load Voltage Inst. Fwd Max
204 SF = 10 Load Voltage Inst. Rev Min
205 SF = 10 Load Voltage Inst. Rev Max
206 SF = 10 Source Voltage Inst. Fwd
207 SF = 10 Source Voltage Inst. Fwd Max
208 SF = 10 Source Voltage Inst. Rev Min
209 SF = 10 Source Voltage Inst. Rev Max
210 SF = 10 Comp Volts Inst. Fwd Min
211 SF = 10 Comp Volts Inst. Fwd Max
212 SF = 10 Comp Volts Inst. Rev Min
213 SF = 10 Comp Volts Inst. Rev Max
214 variable Load Current Inst. Fwd Min (Amps)
215 variable Load Current Inst. Fwd Max (Amps)
216 variable Load Current Inst. Rev Min (Amps)
217 variable Load Current Inst. Rev Max (Amps)
218 SF = 100 PF Inst. Fwd Min
219 SF = 100 PF Inst. Fwd Max
220 SF = 1 KVA Inst. Fwd Min
221 SF = 1 KVA Inst. Fwd Max
