32
222 SF = 1 KVA Inst. Rev Min
223 SF = 1 KVA Inst. Rev Max
224 SF = 1 KW Inst. Fwd Min
225 SF = 1 KW Inst. Fwd Max
226 SF = 1 KW Inst. Rev Min
227 SF = 1 KW Inst. Rev Max
228 SF = 1 KVAR Inst. Fwd Min
229 SF = 1 KVAR Inst. Fwd Max
230 SF = 1 KVAR Inst. Rev Min
231 SF = 1 KVAR Inst. Rev Max
232 SF = 10 Frequency Inst. Fwd Min (Hz)
233 SF = 10 Frequency Inst. Fwd Max (Hz)
234 SF = 1 Tap position Inst. Fwd Min
235 SF = 1 Tap position Inst. Fwd Max
236 SF =1 CM self test result
237 SF = 1 Vref a/d value
238 SF = 1 Raise Limit Reached status
239 SF =1 Lower Limit Reached status
240 SF = 1 CM Response (to Init) Status
241 SF = 1 CM Software Revision
242 SF = 1 CM Hardware Revision
243 SF = 1 CM microprocessor Mask rev.
244 SF = 1 CM I/O Board Type
245 SF = 1 CM Options (to be defined)
246 SF = 1 CM I/O Board Revision
247 SF = 1 CM QSPI MP to CM Errors
248 SF = 1 CM QSPI no. of Failed Writes
249 SF = 1 CM QSPI no. of Xfer Cycles
250 SF = 1 CM DNP no. of requests for not supported items
251 SF = 1 CM RAM Error High Address
252 SF = 1 CM RAM Error Low Address
Analog Outputs
Point # Scale Factor Description
0 SF = 1 Total Operations Count
1 SF = 1 Level 1 PW characters
2 SF = 1 Cfg. PW characters
3 SF = 1 Reg. PW characters
4 SF = 1 Meter PW characters
5 SF = 1 Dmd PW characters
6 SF = 1 Alert PW characters
7 SF = 1 Ops PW characters
8 SF = 1 LogSet PW characters
9 SF = 1 Event/Interval PW characters
10 SF = 1 Harm PW characters
11 SF = 1 Comm PW characters
12 SF = 1 Diag. PW characters
13 SF = 1 Syskey PW characters
14 SF = 1 Raise/Lower Operation
15 variable CT Primary Ratio (Amps)
16 SF = 1 System Line Voltage (Volts)
17 SF = 10 High Voltage Limit (Volts)
18 SF = 10 Low Voltage Limit (Volts)
19 SF = 10 Local Voltage Reduction (%)
20 SF = 10 VRC Remote Setting #1 (%)
21 SF = 10 VRC Remote Setting #2 (%)
22 SF = 10 VRC Remote Setting #3 (%)
23 SF = 1 Auto VRC #1 %Current (%)
24 SF = 1 Auto VRC #2 %Current (%)
