Siemens MJ-4 Series Installation Manual

MJ-4 Communications Module
33
25 SF = 10 Auto VRC #1 % Setting (%)
26 SF = 10 Auto VRC #2 % Setting (%)
27 SF = 1 P2 primary (from P2 PT ratio) (Volts)
28 SF = 1 P2 secondary (Volts)
29 SF = 1000 CT secondary (Amps)
30 SF = 1 Current Shift (in º, relative to voltage)
31 SF = 1 U2 primary (Volts)
32 SF = 1 U2 secondary (from U2 PT ratio) (Volts) (Range: 100-150)
33 SF = 1 PT Threshold (Volts)
34 SF = 1 Date Format
35 SF = 1 Demand Subperiods
36 SF = 10 MJ3A remote mode %VRC
37 SF = 1 Min/Max Time-out(sec)
38 SF = 1 Screen Timeout(minutes)
39 SF = 1 Harm. Show as: RMS/%T/fund.
40 N/A
41 N/A
42 SF = 10 Dmd Time Interval (minutes)
43 SF = 10 Bandwidth (Reverse) (Volts)
44 SF = 10 Line Comp. React. (Rev) (Volts)
45 SF = 10 Line Comp. Resist. (Rev) (Volts)
46 SF = 1 Reverse Sensing Method
47 SF = 10 Set Voltage (Reverse) (Volts)
48 Time Delay (Reverse) (seconds)
49 SF = 1 Reverse Threshold Value (%)
50 SF = 10 Bandwidth (Forward) (Volts)
51 SF = 10 Line Comp. React. (Fwd) (Volts)
52 SF = 10 Line Comp. Resist. (Fwd) (Volts)
53 SF = 1 Control Operating Modes
54 SF = 10 Set Voltage (Forward) (Volts)
55 SF = 1 Time Delay (Forward)(seconds)
56 SF = 1 Control Communications Address
57 SF = 1 Comm Port Baud Rate
58 SF = 1 Comm Port Handshake Mode
59 SF = 1 Communications Port Re-Synch Time Characters (no. characters)
60 SF = 1 Communications Port-Transmit Enable Delay (msec)
61 SF = 1 Regulator Type
62 SF = 1 Utility Winding Polarity
63 SF = 1 Meter Display Volts
64 SF = 1 Demand Type
65 SF = 1 VRC Remote
66 SF = 1 Basis Voltage
67 SF = 1 Harm: Odd Only/Odd & Even
68 SF = 1 Regulator Configuration
69 SF = 1 Voltage Limiting Mode
70 SF = 1 Voltage Reduction Mode
71 SF = 1 Event/Interval Log Setup Status
72 SF = 1 Password Enables, Bit mapped
73 SF = 1 Alert Status word 1 (encoded)
74 SF = 1 Alert Status word 2 (encoded)
75 SF = 1 Memo1 - chars 1-2
76 SF = 1 Memo1 - chars 3-4
77 SF = 1 Memo1 - chars 5-6
78 SF = 1 Memo1 - chars 7-8
79 SF = 1 Memo1 - chars 9-10
80 SF = 1 Memo2 - chars 1-2
81 SF = 1 Memo2 - chars 3-4
82 SF = 1 Memo2 - chars 5-6
83 SF = 1 Memo2 - chars 7-8
