MP270 Operation
4-5
MP270 Equipment Manual
Release 01/99
4.2 Entering Values
Marking
On selecting an input field, the entire field content is marked by changing color.
After pressing a key (except a cursor key), the field content is deleted and the new
input displayed.
Press a cursor key after selecting the field and the field marking changes back; the
cursor can be moved freely within the field.
Operation
Proceed as follows in order to enter values in an input field:
Step Action
1 Use the cursor keys to position the cursor on the desired input field.
2 Enter the value in the following form, according to the configuration:
Numeric (Page 4-6)
Alphanumeric (Page 4-7)
Symbolic (Page 4-8)
3 Confirm the entry.
To Next Page
