Siemens Multi Panel MP270 SIMATIC HMI User Manual

2-1
MP270 Equipment Manual
Release 01/99
Functionality
The following table summarizes the range of functions provided by the MP270. The values
quoted are the maximum values which can be managed by the MP270. The values are limited
by the size of the memory used.
Function Comment
Event messages Number 2000
Display In message line/message window
View all pending messages On message page
Message length per line 70 characters
Lines per message 1
Process values in message text 8
Alarm messages Number 2000
Display In message line/message window
Type of display First/Last
View all pending messages On message page
Message length per line 70 characters
Lines per message 1
Process values in message text 8
Acknowledge individual alarm
messages
4
Acknowledge several alarm
messages simultaneously
(group acknowledgement)
16 acknowledgment groups
Message logging Output to printer 4
Volatile message buffer Capacity 1024 Message events
View event/alarm messages 4
Delete 4
Message events queued
simultaneously (max.)
 Event messages
or
500
 Alarm messages 250
Message buffer archive Capacity Limited by storage medium
2
