inbetriebnahme.fm
A31003-S2010-M100-18-76A9
OpenStage HFA Family, Administration Manual
2-5
Startup
Assembling and Installing the Phone
2.2.4 Connecting the Phone
1. Plug the LAN cable into the connector at the bottom of the telephone and connect the
cable to the LAN/switch. If PoE (Power over Ethernet) is to be used, the PSE (Power Sourc-
ing Equipment) must meet the IEEE 802.3af specification.
For details about the required power supply, see the following table:
2. Only if Power over Ethernet (PoE) is NOT supported:
Plug the power supply unit into the mains. Connect the plug-in power supply unit to the
jack at the bottom of the phone.
3. If applicable, connect the following optional jacks:
LAN connection to PC
Headset (accessory)
Connection to add-on device (accessory)
Model Power Consumption/Supply
OpenStage 15
1
1 Includes 1 Key Module 15.
Power Class 1
OpenStage 15 G
1
Power Class 2
OpenStage 20 Power Class 1
OpenStage 20 E Power Class 1
OpenStage 20 G Power Class 2
OpenStage 40
2
2 Includes 1 Key Module.
Power Class 2
OpenStage 40 + 2nd Key Module Power Class 2
OpenStage 40 G
2
Power Class 3
OpenStage 40 G + 2nd Key Module Power Class 3
OpenStage 60/80
3
3 Includes 1 Key Module + USB-Extension with Acoustic Unit.
Power Class 3
OpenStage 60/80 + 2nd Key Module Power Class 3
OpenStage 60/80 G
3
Power Class 3
OpenStage 60/80 G + 2nd Key Module External power unit required
7
Use only the plug-in power supply unit fitting the OpenStage phone:
EU: C39280-Z4-C510
UK: C39280-Z4-C512
USA: C39280-Z4-C511
