Boards for HiPath 3000 Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

3-200 HiPath 3000/5000 V9, Service documentation

boards.fm

Peripheral boards

3.3.19 SLMO2, SLMO8

Introduction

The SLMO2 and SLMO8 boards (Subscriber Line Module Optiset) provide U

P0/E

interfaces for

optiPoint and OpenStage telephones in HiPath 3800:

● SLMO2 (S30810-Q2168-X10) = 24 U

P0/E

interfaces

● SLMO8 (S30810-Q2168-X100) = eight U

P0/E

interfaces

Front panel

NOTE

Danger of damage to property due to surge voltage. The required lightning protec-

tion measures must be taken for this board, see Section 2.1.2, “Lightning Protec-

tion”.

Figure 3-63 SLMO2/SLMO8 - LEDs on the Front Panel

To ensure sufficient shielding, provide the board with a shielding panel. For informa-

tion on mounting the shielding panel, see Section 4.1.5.3.

Two LEDs indicating the board status:

● LED (red)

● LED (green)
