HiPath 3000/5000 V9, Service documentation
4-123
Nur für den internen Gebrauch Installing HiPath 3000
Installing HiPath 3550, HiPath 3350, HiPath 3500, and HiPath 3300
4.2.4.10 Connecting Workpoint Clients
For information, see Chapter 10.
4.2.4.11 Making Trunk Connections
Refer to the following board descriptions for information:
● STLS4R (S
0
trunk connection)
● TS2R, only HiPath 3500 (S
2M
trunk connection)
● TLA4R (not for U.S.) (MSI)
● TMGL4R (for U.S. only)
● TST1 (for U.S. only), HiPath 3500 only
4.2.4.12 Performing a Visual Inspection
Before starting up the system, you must perform a visual inspection of the hardware, cables,
and the power supply. The visual inspection must be performed while the system is disconnect-
ed from the power supply.
7
Caution
Conduct the visual inspection only while the system is disconnected from the power
supply.
Always wear an antistatic wristband and observe the measures for protecting elec-
trostatically sensitive devices (see Section 1.2.6, “Notes”).
Step Activity Resources/Remarks Possible remedies
1. Compare the slots for the
installed boards with the
board assignment map.
Board assignment map Correct the board
configuration and no-
tify the sales depart-
ment.
2. Check the local line voltage. Digital multimeter
>
After finishing the visual inspection, you can begin starting up the system as de-
scribed in Chapter 5.
