Fail-Safe Modules
7.5 4/8 F-DI DC24V PROFIsafe Digital Electronic Module
ET 200S Distributed I/O System - Fail-Safe Modules
134 Installation and Operating Manual, 08/2008, A5E00103686-07
Technical Specifications
• Between channels
No
• Between channels/power supply and shield
Yes
Permissible potential difference between
• Shield and ET 200S bus connection
75 VDC/60 VAC
• Shield and I/O (DIs, P1/P2 buses)
75 VDC/60 VAC
• ET 200S bus connection and I/O (DIs, P1/P2
buses)
250 VAC
Isolation in the series tested with
• Shield and ET 200S bus connection
500 VDC/1 min or 600 VDC/1 s
• Shield and I/O (DIs, P1/P2 buses)
500 VDC/1 min or 600 VDC/1 s
• ET 200S bus connection and I/O (DIs, P1/P2
buses)
1500 VAC/1 min or 2545 VDC/1 s
Isolation in the type test tested with
• Shield and ET 200S bus connection
350 VAC/1 min
• Shield and I/O (DIs, P1/P2 buses)
350 VAC/1 min
• ET 200S bus connection and I/O (DIs, P1/P2
buses)
2830 VAC/1 min
• Surge voltage test between ET 200S bus
connection and I/O (DIs, P1/P2 bus)
6000 VDC/5 positive and 5 negative pulses
Current consumption
• From backplane bus
28 mA, typical
• From load voltage L+ (without load)
120 mA, typical
Power dissipation of the module 4 W, typical
Status, Interrupts, Diagnostics
Status display
Inputs Green LED per channel
Sensor supply Red LED per channel
Diagnostic functions
• Group fault display
Red LED (SF)
• Diagnostic information can be displayed
Possible
Sensor Supply Outputs
Number of outputs 2
Output voltage
• Loaded
Minimum L+ (-1.5 V)
Output current
• Rated value
300 mA
• Permissible range
0 mA to 300 mA
Permissible total current of outputs 600 mA
Short-circuit protection Yes, electronic
• Operating value
0.7 A to 1.8 A
Data for selecting a sensor ***
Input voltage
• Rated value
24 VDC
• For "1" signal
15 V to 30 V
• For "0" signal
-30 V to 5 V
