Configuring

2.2 Assigning Modules of an ET 200S

ET 200S Distributed I/O System - Fail-Safe Modules

22 Installation and Operating Manual, 08/2008, A5E00103686-07

2.2 Assigning Modules of an ET 200S

Introduction

This section presents the ET 200S module assignments for:

● Fail-safe power modules to terminal modules

● Fail-safe electronic modules to terminal modules

● Power modules to electronic modules/motor starters

Assigning Fail-Safe Power Modules to Terminal Modules

You can use the F-power modules with the following terminal modules:

Table 2- 1 Assigning Fail-Safe Power Modules to Terminal Modules

F-Power Modules Terminal Modules For a Description, See ...

TM-P30S44-A0 (screw-in type) PM-E F pm DC24V PROFIsafe

and

PM-E F pp DC24V PROFIsafe

TM-P30C44-A0 (snap-in type)

PM-D F DC24V PROFIsafe TM-PF30S47-F1 (snap-in type)

Terminal Modules

manual

for the ET 200S

distributed I/O system

Assigning Fail-Safe Electronic Modules to Terminal Modules

You can use the following fail-safe electronic modules and terminal modules together:

Table 2- 2 Assigning Fail-Safe Electronic Modules to Terminal Modules

F-Electronic Modules Terminal Modules For a Description, See ...

TM-E30S46-A1 (screw-in type)

TM-E30C46-A1 (snap-in type)

TM-E30S44-01 (screw-in type)

4/8 F-DI DC24V PROFIsafe,

4 F-DI/3 F-DO DC24V

PROFIsafe, 4 F-DODC24V/2A

PROFIsafe and

1 F-RO DC24V/AC24..230V/5A

TM-E30C44-01 (snap-in type)

ET 200S Distributed

I/O System

Operating

Instructions
