7.3 PM-E F pp DC24V PROFIsafe power module
ET 200S Distributed I/O System - Fail-Safe Modules
Installation and Operating Manual, 08/2008, A5E00103686-07
93
7.3.6 Technical Specifications for the PM-E F pp 24 VDC PROFIsafe
Overview
Technical Specifications
Dimensions and Weight
Dimensions W x H x D (mm) 30 x 81 x 52
Weight Approx. 80 g
Data for Specific Module
Number of outputs
• Relay outputs (PP switching)
1
Assigned address area
• In the I/O area for inputs
5 bytes
• In the I/O area for outputs
5 bytes
Length of cable
• Unshielded
200 m, maximum
• Shielded
200 m, maximum
Maximum achievable safety class
• according to IEC 61508, according to EN 954,
according to ISO 13849
SIL3, category 4, PLe (for conditions see "Power
modulePM-E F pp DC24V PROFIsafe")
Fail-safe performance characteristics SIL3
• Low demand mode (average probability of
failure on demand)
< 1.00E-05
• High demand/continuous mode (probability of
a dangerous failure per hour)
< 1.00E-10
• Acceptance ID
FM, cULus, CE, C-Tick
Voltages, Currents, Potentials
Rated supply voltage L+ 24 VDC
• permissible range **
20.4 V to 28.8 V
• Power loss ride-through of L+
None
• Power loss ride-through of internal P5
5 ms
• Reverse polarity protection
No
Total current of the relay output
• Horizontal installation
– Up to 40 °C
– Up to 55 °C
– Up to 60 °C
10 A
8 A
7 A
• Vertical installation
– Up to 40 °C
8 A
