Siemens PM-E F pm DC24V PROFIsafe User Manual

Wiring and Fitting Modules
4.3 Wiring fail-safe modules
ET 200S Distributed I/O System - Fail-Safe Modules
Installation and Operating Manual, 08/2008, A5E00103686-07
35
Mounting Rails
The ET 200S distributed I/O system is installed on a mounting rail according to EN 60715
(35 x 7.5 mm or 35 x 15 mm).
Appropriate surface designs are:
● Steel strip according to Appendix A of EN 60715, or
● Tinned steel strip. We recommend the following mounting rails for this purpose:
– 6ES5710-8MA11 (length: 483 mm)
– 6ES5710-8MA21 (length: 530 mm)
– 6ES5710-8MA31 (length: 830 mm)
– 6ES5710-8MA41 (length: 2000 mm)
Note
If you use rails from other manufacturers, please ensure that these have the properties
necessary to withstand your climatic ambient conditions.
Terminal assignment of the TMs
The terminal assignment of the TMs depends on the installed power or electronic module.
See also
Wiring of the PM-E F pm DC24V PROFIsafe (Page 70)
Wiring of the PM-E F pp DC24V PROFIsafe (Page 88)
Wiring of the PM-D F DC24V PROFIsafe (Page 100)
Wiring of the EM 4/8 F-DI DC24V PROFIsafe (Page 108)
Wiring of EM 4 F-DI/3 F-DO DC24V PROFIsafe (Page 141)
Wiring diagram of the EM 4 F-DO DC24V/2A PROFIsafe (Page 167)
Wiring of EM 1 F-RO DC24V/AC24..230V/5A (Page 181)
