Fail-Safe Modules
7.2 PM-E F pm DC24V PROFIsafe Power Module
ET 200S Distributed I/O System - Fail-Safe Modules
80 Installation and Operating Manual, 08/2008, A5E00103686-07
Technical Specifications
• Shield and I/O (DOs, P1/P2 buses)
350 VAC/1 min
• ET 200S bus connection and I/O (DOs,
P1/P2 buses)
2830 VAC/1 min
• Surge voltage test between ET 200S bus
connection and I/O (DOs, P1/P2 buses)
6000 VDC/5 positive and 5 negative pulses
Current consumption
• From backplane bus
28 mA, maximum
• From load voltage L+ (without load)
100 mA, typical
Power dissipation of the module 4 W, typical
Status, Interrupts, Diagnostics
Status display
• Green LED per channel
• Green LED for the load voltage
Diagnostic functions
• Group fault display
Red LED (SF)
• Diagnostic information can be displayed
Possible
Data for selecting an actuator for the semiconductor outputs***
Output voltage
• For "1" signal • Minimum L+ (-2.0 V)
• P-switch: minimum L+ (-1.5 V), voltage drop in
M-switch: Maximum, 0.5 V
Output current for "1" signal
• Rated value
2 A
• Permissible range
20 mA to 2.4 A
For "0" signal (residual current) 0.5 mA, maximum
Indirect control of load by means of interface
relay:
Residual current for "0" signal
• P-switch
0.5 mA, maximum
• M-switch
4 mA, maximum
Load resistance range 12 Ω to 1 kΩ
Lamp load 10 W, maximum
Wire break monitoring (open load detection) and
overload monitoring
• Response threshold
I < 4 to 19 mA
• Fault detection time
depending on the selected readback time (see
"Response Times"
)
Parallel connection of 2 outputs Not possible
Control of a digital input Not possible
Switching frequency
• With resistive load
30 Hz symmetrical, maximum
• With inductive load in accordance with IEC
60947-5-1, DC13
0.1 Hz symmetrical, maximum
