151 / 244
Siemens Standard application AHU CE1P3977en_02
Building Technologies SD card and modem 01.02.2010
Parameter Range Function
SMS language 30. English
31. Swedish
32. German
33. Lang4
34. Lang5
Displays language used to send any potential
SMS.
Send string Displays modem initialization string for send.
Receive string Displays modem initialization string for receive.
Spezial settings Go to modem settings page to enter required
parameters, e.g. initialization string.
Value Operating state
0 OK; SMS
1 OK; general
2 Modem is initializing
3 Modem is transferring data
4 Modem is not logged on with the provider
5 Searching for network
6 Provider prevented network logon
7 Unknown registration state
8 Modem is making connection
9 Modem is connected
10 General error, modem not responding, possibly no modem connected
11 Modem initialization failed
Main Index > System overview > Communication > Modem > Modem Special
Settings
Parameter Range Function
Enable bus LED 35. No
36. Yes
Enable bus LED
OFF = No modem connected or LED is not en-
abled
Yellow = Modem connected and initialized no
communication active
Green = Modem connected and communication
active
Red = Modem connected but errors active (such
as provider missing, no initialization possible...)
Init string 1 Modem initialization string 1.
Init string 2 Modem initialization string 2 (additional).
Force Reset 37. Passive
38. Active
Reset modem with new initialization.
SMS POU mode 39. Passive
40. Active
Passive: SMS are sent as text message.
Active: SMS sent in PDU mode (some older cell
phones can only use this mode).
Cell phone 41. Passive
42. Active
Passive: A GSM modem connected as sender.
Active: Cell phone connected as sender.
Baud rate(19200) 43. Passive
44. Active
Passive: Baud rate between controller and mo-
dem is 57.6 kbps.
Active: Baud rate is 19.2 kbps.
Description of states
Parameterize modem
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 151
