17.20.2 Fan settings
Main Index > Unit > Operation Hours > Fan Settings
Parameter Function Value range Unit Standard R S Link
OpHours alarm Operation hours alarm Active, Passive X
Enble alarmOpHours Enables this Function, if the Operation
Hours from Supply Fan are > than OpHours
Limit => alarm
No, Yes No 6
OpHours Limit Operation hours Limit 0…999999 h 17520 6
17.21 Alarm handling (Alarm outputs)
Main Index > Alarm handling
Parameter Function Value range Unit Standard R S Link
Alarm acknowledge Reset button for Alarms Off, On 4
Danger (A) Aktual Status of Danger Alarms Normal, Alarm X
Critical (A) Aktual Status of Critical Alarms Normal, Alarm X
Low (B) Aktual Status of Low Alarms Normal, Alarm X
Warning (C) Aktual Status of Warnings Normal, Alarm X
Alarm outp 1 select Selection of signalised Alarms if only one
Alarm output is activated
High (A) = only High class Alarms
H+L (A+B) = High and Low class Alarms
High (A)
H+L (A+B)
4
Alarm output 1 Actual Status from output 1 Normal, Alarm X
Alarm output 2 Actual Status from output 2 Normal, Alarm X
Modbus communicat Error Status from MODBUS communication
(1 = Alarm)
0…1 X
Comm module 0 Jumpline to Communication modele
overview
4
Comm failure Comminication failure in Module 0 Passive, Active X
State Reason for Failure in Module 0 Ok
Hardware
Init
Memory
DoubleID
COV Reg
other
X
Section:
5.14
Comm module 1 Jumpline to Communication module
overview
4
Comm failure Comminication failure in Module 1 Passive, Active X
State Reason for Failure in Module 1 Ok
Hardware
Init
Memory
DoubleID
COV Reg
other
X
Comm module 2 Jumpline to Communication module
overview
4
Comm failure Comminication failure in Module 2 Passive, Active X
State Reason for Failure in Module 2 Ok
Hardware
Init
Memory
DoubleID
COV Reg
other
X
