15.4 Check config I/Os
Hardware assignments made in Configuration I/Os are checked using this function:
• Check whether and what points are not assigned.
• Checks whether hardware inputs or outputs exists that are occupied in duplicate.
Configuration 1 and Configuration 2 completed with one reset each.
As required:
Start page > Password Enter
then:
Main Index > Configuration > Check config IO’s
Parameter Range Function
Not config IO 11. No
12. Yes
Displays whether there are unassigned I/Os.
1st notconfig IO pos 0, 1, ... Displays the position of the first unassigned I/O. The associated
plant elements are available in the table in appendix
20.2
Diagnostic tables for check I/O.
Doubled config IO 13. No
14. Yes
Displays whether hardware input or outputs are occupied in dupli-
cate.
Doubled config IO’s Displays positions of the first double occupancy. The associated
plant elements are available in the table in appendix
20.2
Diagnostic tables for check I/O.
Doubled config IO pos XO1...XO28 Displays the first double occupied input or output (exception: DO).
Doubled config DO pos DO1...DO24 Displays first double occupied DO.
Not used xIO 0... [pcs] Displays number of unused universal inputs/outputs.
Not used DI 0... [pcs] Displays the number of unused digital inputs.
Not used AO 0... [pcs] Displays the number of unused analog outputs.
Not used DO 0... [pcs] Displays the number of unused digital outputs.
