Siemens Standard application AHU CE1P3977en_02
Building Technologies HMI 01.02.2010
Main Index > Unit > Loop controllers
Parameter Function Value range Unit Standard R S Link
Max supply tmp Actual Value; Jumpline to Controller settings 0…100 % X
Hrec damper Actual Value; Jumpline to Controller settings 0…100 % X
Heat recovery Actual Value; Jumpline to Controller settings 0…100 % X
Hrec frost protect Actual Value; Jumpline to Controller settings 0…100 % X
Hrec frost pressure Actual Value; Jumpline to Controller settings 0…100 % X Chapter:
Heating Actual Value; Jumpline to Controller settings 0…100 % X
7.1
Htg frost protect Actual Value; Jumpline to Controller settings 0…100 % X
Electrical heating Actual Value; Jumpline to Controller settings 0…100 % X
Casc controller hum Actual Value Hum/Dehum; Jumpline to
Controller settings
0…100 %rH X
Max supply hum Actual Value; Jumpline to Controller settings 0…100 % X
Humidification Actual Value; Jumpline to Controller settings 0…100 % X
Dehumidification Actual Value; Jumpline to Controller settings 0…100 % X
Fan comp humidity Actual Value; Jumpline to Controller settings 0…100 % X
Cooling Actual Value; Jumpline to Controller settings 0…100 % X
Heating 2 Actual Value; Jumpline to Controller settings 0…100 % X
El Heating 2 Actual Value; Jumpline to Controller settings 0…100 % X
Cooling 2 Actual Value; Jumpline to Controller settings 0…100 % X
Fan heating Actual Value; Jumpline to Controller settings 0…100 % X
Fan cooling Actual Value; Jumpline to Controller settings 0…100 % X
Fan comp tmp Actual Value; Jumpline to Controller settings 0…100 % X
17.20 Operation hours
17.20.1 General
Main Index > Unit > Operation Hours
Parameter Function Value range Unit Standard R S Link
Supply fan Supply Fan operation hours h
Reset.
Supply Fan operation hours Reset Active, Passive Active 6
Exhause fan Exhaust fan operation hours h
Reset.
Exhaust fan operation hours Reset Active, Passive Active 6
Fan settings Jumpline to Fan settings 6
Hrec (pump)/cmd Heat Recovery Pump Operation Hours h 4
Reset.
Heat Recovery Pump Operation Hours
Reset
Active, Passive Active 6
Heating pump Heating pump Operation Hours h
Reset.
Heating pump Operation Hours Reset Active, Passive Active 6
Electrical heating Electrical heating Cmd Operation Hours h
Reset.
Electrical heating Cmd Operation Hours
Reset
Active, Passive Active 6
Cooling pump Cooling Pump Operation Hours h X Section:
Reset.
Cooling Pump Operation Hours Reset Active, Passive 6
5.4.6
Cooling DX Digital Cooling Operation Hours h X
Reset.
Digital Cooling Operation Hours Reset Active, Passive 6
Humidifier Humidity Cmd Operation Hours h X
Reset.
Humidity Cmd Operation Hours Reset Active, Passive 6
Humidifier pump Humidity Pump Operation Hours h X
Reset.
Humidity Pump Operation Hours Reset Active, Passive 6
Heating 2 pump Heating 2 Pump Operation Hours h X
Reset.
Heating 2 Pump Operation Hours Reset Active, Passive 6
El heating 2 Electrical heating 2 Cmd Operation Hours h X
Reset.
Electrical heating 2 Cmd Operation Hours
Reset
Active, Passive 6
Cooling 2 pump Cooling 2 Pump Operation Hours h X
Reset.
Cooling 2 Pump Operation Hours Reset Active, Passive 6
Cooling 2 Dx Extra DX Cooling Operation Hours h X
Reset.
Extra DX Cooling Operation Hours Reset Active, Passive 6
Aux Tsp Output Auxiliary Time Schedule output Operation
Hours
h X
Reset.
Auxiliary Time Schedule Operation Hours
Reset
Active, Passive 6
