18.4.3 Priority array
Main Index > Unit > Outputs > Digital outputs > Element > Priority array
Parameter Function Value range Unit Standard R S Link
Default Replacement value, when no priority is
active.
Off
Stage1
Stage2
Stage3
NULL
6 X
Prio 01 Value for priority 1. Off
Stage1
Stage2
Stage3
NULL
6 X
Section:
6.4.3
... ... ...
Priority 16 Value for priority 16. Off
Stage1
Stage2
Stage3
NULL
6 X
18.5 Detail pages: Analog inputs
18.5.1 General
Main Index > Unit > Inputs > Element group > Element
Parameter Function Value range Unit Standard R S Link
Present Value Present input value. Depends on hardware. 6 4
Reliability (Basis
Controller)
Reliability state for hardware.
Interrupt.
Value outside measuring range on 0-10V
DC inputs.
Short circuit.
Calibration lacking. Controller must be re-
turned to the factory.
Internal fault.
Input not configured.
OK.
No sensor
Over range
Shorted loop
Other
Process Error
Config Error
6 4
Reliability (Extension
Modul POL 955)
Reliability state for hardware.
Value outside measuring range on 0-10V
DC inputs.
Interrupt for passive sensors.
Short circuit for passive sensors.
Calibration lacking. Controller must be re-
turned to the factory; internal fault or input
not configured.
OK.
Over range
Under range
Other
6 4
Section:
6.5.1
High limit active Display an Off normal Alarms, when Pre-
sent Value > High limit.
Passive
Active
6 4
High limit active Display an Off normal Alarms, when Pre-
sent Value < Low limit.
Passive
Active
6 4
High limit Limit value for a high-limit alarm. Depends on hardware. 6 4
Low limit Limit value for a low-limit alarm. Depends on hardware. 6 4
Sensor correction Sensor correction value. Depends on hardware. 6 4
PT1 filter HW Time constant for the input filter. 0…32767 [s] 6 4
Time delay Alarm time delays for off normal alarms. 0…65535 [s] 6 4
Special settings Go to special settings page. 4
Special infos Go to special info page. 4
