17.13 Damper control
17.13.1 Start page
Main Index > Unit > Damper control
Parameter Function Value range Unit Standard R S Link
Off delay by fanoff Delay Off Time for Supply, Exhaust and Fire
damper
0…36000 --- S --- 10 6
Damper Jumpline to Supply and Exhaust Damper
settings
6 Section:
5.3.1
Fire damper Actual Command; Jump line to Fire damper
settings
On…Off 6
17.13.2 Damper
Main Index > Unit > Damper Control > Damper
Parameter Function Value range Unit Standard R S Link
Outside air cmd Command Outside air Damper (combined
Damper)
On…Off X
Outside air fdbk Outside air Damper Feedback (combined
Damper)
No…Yes X
Outs offby fdbk alm Take akway Command in case of Feedback
alarm
No…Yes Yes 6
StrtUpDly outs fdbk Delay time until Feedback = 1 0…36000 --- S --- 180 6 Section:
Extract air cmd Command Extract Damper (combined
Damper)
On…Off X
5.3.2
Extract air fdbk Extarct Damper Feedback (combined
Damper)
No…Yes X
Extr offby fdbk alm Take akway Command in case of Feedback
alarm
No…Yes Yes 6
StrtUpDly Extr fdbk Delay time until Feedback = 1 0…36000 --- S --- 180 6
Opening time Default Open time for Dampers if no real
Feedback
0…36000 --- S --- 20 6
17.13.3 Fire damper
Main Index > Unit > Damper Control > Fire damper
Parameter Function Value range Unit Standard R S Link
Command Command Fire damper On…Off X
Feedback opened Feedback Damper opened OK…No X
Feedback closed Feedback Damper closed Ok…No X
No move Message if Damper do not follow Command Ok…ALarm X
State State of the Fire damper NDef
Clsd
Move
Opnd
X
Mode Operation Mode Fire damper NDef
Ok
Debug
Alm
X Section:
5.3.3
Opening time Open Time for Fire damper 0…36000 --- S --- 6
Closing time Close Time for Fire damper 0…36000 --- S --- 6
Start manual test Direct start from Auto Test over HMI Passive
Aktive
Passive 6
Auto Test Date and Time for Auto Test 6
auto test interval Interval for Auto Test 0…3600 h 6
