Siemens Standard application AHU CE1P3977en_02
Building Technologies Configuration 01.02.2010
HW IO Pos
Emergency stop NUsd,Comm,X4...X28,DI1...DI5
Su-wi input NUsd,Comm,X4...X28,DI1...DI5
Alarm ackn button NUsd,Comm,X4...X28,DI1...DI5
Auxiliary input NUsd,Comm,X4...X28,DI1...DI5
Position Explanation
X4...X8 Terminal on basis controller.
DI1...DI5 Terminal on basis controller.
X11...X18 Terminal on extension module 1.
X21...X28 Terminal on extension module 2.
Comm Function is connected via communication and therefore does not
occupy a hardware input. Some signals can also be connected via
communication (see lists in the documentation on the basics for
LON, ModBus, BacNet).
Signals may generally be enabled in parallel as well (via hardware
and communication).
The value selector must be set accordingly when enabling via com-
munication (for details page on Digital Inputs, Sec.
6.6.2.).
NUsd No used: The hardware position is not yet selected. The plant is
locked against switching on if an enabled sensor is set to NUsd and
the following fault issued: NotConfigured (Function enabled, but
hardware not assigned).
15.3.6 Digital alarms
The listed hard assignments are possible for all digital alarms.
HW IO Pos
Htg frost protect,
Heating pump...Auxiliary
NUsd,Comm,X4...X28,DI1...DI5
Position Explanation
X4...X8 Terminal on basis controller.
DI1...DI5 Terminal on basis controller.
X11...X18 Terminal on extension module 1.
X21...X28 Terminal on extension module 2.
Comm Function is connected via communication and therefore does not
occupy a hardware input. Some signals can also be connected via
communication (see lists in the documentation on the basics for
LON, ModBus, BacNet).
Signals may generally be enabled in parallel as well (via hardware
and communication).
The value selector must be set accordingly when enabling via
communication (for details page on Digital Inputs, Sec.
6.6.2.).
NUsd No used: The hardware position is not yet selected. The plant is
locked against switching on if an enabled sensor is set to NUsd
and the following fault issued: NotConfigured (Function enabled,
but hardware not assigned).
