15.3.11 Outputs: Humidifier
The listed hard assignments are possible for all outputs.
HW IO Pos
Humidifier AO NUsd,Comm,X3..X28,AO1...AO22
Humidifier DO NUsd,Comm,DO1..DO24
Humidifier pump DO NUsd,Comm,DO1..DO24
Position Explanation
DO1...DO6 Terminal on basis controller.
DO11...DO14 Terminal on extension module 1.
DO21...DO24 Terminal on extension module 2.
Comm This output is connected via communication and therefore does
not occupy a hardware input. Some output signals can also be
connected via communication (see lists in the documentation on
the basics for LON, ModBus, BacNet).
Outputs may generally be enabled in parallel as well (via hardware
and communication).
NUsd No used: The hardware position is not yet selected. The plant is
locked against switching on if an enabled sensor is set to NUsd
and the following fault issued: NotConfigured (Function enabled,
but hardware not assigned).
Position Explanation
X3...X8 Terminal on basis controller.
AO1,AO2 Terminal on basis controller.
X11...X18 Terminal on extension module 1.
AO11,AO12 Terminal on extension module 1.
X21...X28 Terminal on extension module 2.
AO21,AO22 Terminal on extension module 2.
Comm This output is connected via communication and therefore does not
occupy a hardware input. Some output signals can also be con-
nected via communication (see lists in the documentation on the
basics for LON, ModBus, BacNet).
Outputs may generally be enabled in parallel as well (via hardware
and communication).
NUsd No used: The hardware position is not yet selected. The plant is
locked against switching on if an enabled sensor is set to NUsd
and the following fault issued: NotConfigured (Function enabled,
but hardware not assigned).
15.3.12 Outputs: Auxiliary
The listed hard assignments are possible for all outputs.
HW IO Pos
Auxiliary A outp NUsd,Comm,X3..X28,AO1...AO22
TSP output DO NUsd,Comm,DO1..DO24
Aux op mode ind DO NUsd,Comm,DO1..DO24
Position Explanation
DO1...DO6 Terminal on basis controller.
DO11...DO14 Terminal on extension module 1.
Terminal positions for
digital outputs
Klemmenpositionen
analoge Ausgänge
(0...10 V DC)
Terminal positions for
digital outputs
