Siemens POL638 Series

187 / 244
Siemens Standard application AHU CE1P3977en_02
Building Technologies HMI 01.02.2010
17.8.8 Outputs fans
Main Index > Configuration > Configuration IO’s > IO conf fan outp
Parameter Function Value range Unit Standard R S Link
Supply fan DO1 IO Position Supply fan Stage 1 NUsd,Comm,DO1...DO2
4
NUsd 4
Supply fan DO2 IO Position Supply fan Stage 2 NUsd,Comm,DO1...DO2
4
NUsd 4
Supply fan DO3 IO Position Supply fan Stage 3 NUsd,Comm,DO1...DO2
4
NUsd 4
Exhaust fan DO1 IO Position Exhaust fan Stage 1 NUsd,Comm,DO1...DO2
4
NUsd 4 Section:
Exhaust fan DO2 IO Position Exhaust fan Stage 2 NUsd,Comm,DO1...DO2
4
NUsd 4
15.3.9
Exhaust fan DO3 IO Position Exhaust fan Stage 3 NUsd,Comm,DO1...DO2
4
NUsd 4
Supply fan AO IO Position Supply fan analog Output NUsd,Comm,X3...X28,
AO1...AO22
NUsd 4
Exhaust fan AO IO Position Exhaust fan analog outputl NUsd,Comm,X3...X28,
AO1...AO22
NUsd 4
17.8.9 Outputs temperature control
Main Index > Configuration > Configuration IO’s > IO conf tmp outp
Parameter Function Value range Unit Standard R S Link
El heating AO IO Position Electrical Heater analog output NUsd,Comm,X3...X28,
AO1...AO22
NUsd 4
El heating DO1 IO Position Electrical Heater Stage 1 NUsd,Comm,DO1...DO2
4
NUsd 4
El heating DO2 IO Position Electrical Heater Stage 2 NUsd,Comm,DO1...DO2
4
NUsd 4
Heating AO IO Position Heater analog output NUsd,Comm,X3...X28,
AO1...AO22
NUsd 4
Heating pump DO IO Position Heater Pump NUsd,Comm,DO1...DO2
4
NUsd 4
Hrec damper AO IO Position Heat recovery damper analog
output
NUsd,Comm,X3...X28,
AO1...AO22
NUsd 4
Heat recovery AO IO Position Heat recovery analog output NUsd,Comm,X3...X28,
AO1...AO22
NUsd 4
Hrec pump DO IO Position Heat recovery Pump NUsd,Comm,DO1...DO2
4
NUsd 4
Cooling AO IO Position Cooling analog output NUsd,Comm,X3...X28,
AO1...AO22
NUsd 4 Section:
15.3.10
Cooling pump DO IO Position Cooling Pump NUsd,Comm,DO1...DO2
4
NUsd 4
Cooling DX DO1 IO Position DX Cooling Stage 1 NUsd,Comm,DO1...DO2
4
NUsd 4
Cooling DX DO2 IO Position DX Cooling Stage 2 NUsd,Comm,DO1...DO2
4
NUsd 4
El heating 2 AO IO Position Electrical Heater 2 analog
output
NUsd,Comm,X3...X28,
AO1...AO22
NUsd 4
El heating 2 DO1 IO Position Electrical Heater 2 Stage 1 NUsd,Comm,DO1...DO2
4
NUsd 4
El heating 2 DO2 IO Position Electrical Heater 2 Stage 2 NUsd,Comm,DO1...DO2
4
NUsd 4
Heating 2 AO IO Position Heater 2 analog output NUsd,Comm,X3...X28,
AO1...AO22
NUsd 4
Heating 2 pump DO IO Position Heater 2 Pump NUsd,Comm,DO1...DO2
4
NUsd 4
Cooling 2 AO IO Position Cooling 2 analog output NUsd,Comm,X3...X28,
AO1...AO22
NUsd 4
Cooling 2 pump DO IO Position Cooling 2 Pump NUsd,Comm,DO1...DO2
4
NUsd 4
Cooling 2 DX DO1 IO Position DX Cooling 2 Stage 1 NUsd,Comm,DO1...DO2
4
NUsd 4
Cooling 2 DX DO2 IO Position DX Cooling 2 Stage 2 NUsd,Comm,DO1...DO2
4
NUsd 4
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 187
