Main Index > Unit > Inputs > Pressures/Flows
Parameter Function Value range Unit Standard R S Link
Exhaust air flow Exhaust air flow 0…40000 l/s x
HrecFrost Pressure Heat recovery Frost Pressure 0…5000 Pa
17.11.3 Humidity
Main Index > Unit > Inputs > Humidity
Parameter Function Value range Unit Standard R S Link
Supply Rel Supply Humidity relative 0…100 %rH x Section:
Room Rel Room Humidity relative 0…100 %rH x
15.3.4
Outside Rel Outside Humidity relative 0…100 %rH x
17.11.4 Other
Main Index > Unit > Inputs > Other
Parameter Function Value range Unit Standard R S Link
AirQuality Air Quality 0…3000 ppm x
ExtSetpoint External setpoint (abslute or shifting) -64.0…64.0 °C x Section:
Settings Jump line to Curve settings for External
setpoint
15.3.7
17.11.5 Digital inputs
Main Index > Unit > Inputs > Digital Inputs
Parameter Function Value range Unit Standard R S Link
Emergency stop Emergency stop On…Off x
SuWi Input External Switch for Summer Winter change
over
Winter…Summer x
Ext control input1 External Switch1 for switching the Unit On…Off x
Ext control input2 External Switch2 for switching the Unit On…Off x
Alarm ackn button Alarm ackn button active…passive x Section:
FireDamper Opened Fire damper Feedback Opened OK…Fault x
15.3.5
FireDamper Closed Fire damper Feedback Closed OK…Fault x
SupplyDamper fdbk Supply Damper Feedback Opened OK…Fault x
ExhaustDamper fdbk Exhaust Damper Feedback Opened OK…Fault x
Auxiliary input Auxiliary input On…Off x
17.11.6 Digital alarms
Main Index > Unit > Inputs > Digital alarms
Parameter Function Value range Unit Standard R S Link
Fire External Fire alarm OK…Fault x
Fan If combined Fan generally Fan alarm OK…Fault x
Supply Fan Supply Fan alarm OK…Fault x
SupplyFan fdbk Supply Fan Feedback (eg. Pressure Switch) OK…Fault x
ExhaustFan Exhaust fan alarm OK…Fault x
ExhaustFan fdbk Exhaust fan Feedback (eg. Pressure Switch) OK…Fault x
Filter Filter alarm (only if combined Fan) OK…Fault x
Supply Filter Supply Filter alarm OK…Fault x
Exhaust Filter Exhaust Filter alarm OK…Fault x
Frost protect hrec Heat recovery Frost monitor OK…Fault x
Hrec Heat recovery alarm OK…Fault x
HrecPump Heat recovery Pump alarm OK…Fault x
HrecPump fdbk Heat recovery Pump Feedback OK…Fault x
Htg frost protect Htg frost protect Detector OK…Fault x
Heating pump Heating pump alarm OK…Fault x Section:
HtgPump fdbk Heating pump Feedback OK…Fault x
ElHeating Electrical Heater alarm OK…Fault x
Humidifier fdbk Humidification Feedback OK…Fault x
Humidifier pump Humidification Pump alarm OK…Fault x
HumidifierPump fdbk Humidification Pump Feedback OK…Fault x
CoolingDx Dx Cooling alarm OK…Fault x
