Operating hours are recorded separately. A message can be triggered upon reach-
ing a certain number of operating hours for the supply air fan.
Main Index > Unit > Fan Control > Supply fan
Main Index > Unit > Fan Control > Exhaust fan
Parameter Range Function
Actual Value xx [l/s], [Pa] Depends on control type (fan control mode), e.g. present value of
pressure.
Controller 0…100 [%] Present value for the controller. Go to page with all controller set-
tings.
Output signal 0…100 [%] Present value for output. Go to page with all analog output set-
tings.
Command – Off
– Stage 1
– Stage 2
– Stage 3
Present state of fan. Go to page with all digital modulating output
settings.
Fdbk – Alarm
– Ok
Condition: Master Index > Configuration > Configuration 2 > Fan
fdbk <> No.
Present value of the feedback. Go to page with all digital input set-
tings. For example, you can set the time for jitter protection (De-
fault: 5 s).
Alarm – Ok
– Alarm
Condition: Master Index > Configuration > Configuration 2 > Fan
alarm <> No.
Present alarm state of fan. Go to page with all digital input settings.
For example, you can set the time for jitter protection (Default: 0 s).
Alarm – Ok
– Alarm
For supply air fan only!
Condition: Master Index > Configuration > Configuration 2 > Fan
alarm <> Combined.
Present alarm state for both fans. Go to page with all digital input
settings. For example, you can set the time for jitter protection (De-
fault: 0 s).
Setpoints/settings xx [%], [l/s],
[Pa]
Depends on control type (fan control mode), present calculated
setpoint. Go to parameter settings page for supply air fan.
Main Index > Unit > Fan Control > Supply fan > Setpoints/Settings
Main Index > Unit > Fan Control > Exhaust fan > Setpoints/Settings
Parameter Range Function
Actual step –
– Off
– Stage1
– Stage2
– Stage3
Present fan stage.
– Off.
– Stage 1 (setpoint 1) active.
– Stage 2 (setpoint 2) active.
– Stage 3 (setpoint 3) active.
Act supply stpt 0...100 [%]
0...40'000 [l/s]
0...5000 [Pa]
Depends on control type (fan control mode <> Direct or
DirectVar): Present calculated setpoint for fan.
Stage 1 0...100 [%]
0...40'000 [l/s]
0...5000 [Pa]
Depends on control type (fan control mode <> Direct or
DirectVar): Setpoint for stage 1 (TSP steps >= 1 for con-
trolled fans).
Stage 2 0...100 [%]
0...40'000 [l/s]
0...5000 [Pa]
Depends on control type (fan control mode <> Direct or
DirectVar): Setpoint for stage 2 (TSP steps >= 2 for con-
trolled fans).
Stage 3 0...100 [%]
0...40'000 [l/s]
0...5000 [Pa]
Depends on control type (fan control mode <> Direct or
DirectVar): Setpoint for stage 3 (TSP steps = 3 for con-
trolled fans).
