MAN-100472 RD150 - Operating Instructions
57030-EN-180717
The following languages are available:
German
English
French
Spanish
Russian
Italian
Dutch
Portuguese
Turkish
Polish
Czech
Inthismenuitemyoudenetheindicationofthemeasuredvalues
on the display. The selection comprises the current value in mA or as
scaled value as well as the HART values PV, SV, TV, QV.
The display values can be adjusted separately.
The default setting for the display value is "Current".
The display and adjustment module has a backlight for the display.
Inthismenuitemyoucanswitchonthelighting.Youcanndthe
required operating voltage in chapter "Technical data".
Thelightingisswitchedoindeliverystatus.
Note:
Thelightingswitchesoautomaticallywhenthecurrentinthesignal
circuit is lower than 4 mA.
It switches on automatically when the current in the signal circuit is
4 mA or higher.
Todampprocess-dependentmeasuredvalueuctuations,setan
integration time of 0 … 999 s in this menu item. The increment is 0.1 s.
Theenteredintegrationtimeinuencesthecurrentvalueandthe
display.TheHARTvalueremainsunaected.
Setup - Display, indica-
tion value 1 to 4
Setup - Display, lighting
Setup - Damping
