Siemens RDB160BN - Binary Inputs and Values

Communication
Communication objects
8
A6V11917618_en
--_b 29 | 52
Object
name
Object ID
Description
Unit
Writeable
FanVarSpd
Max
Analog value, 28
Highest possible
speed for the DC fan
%
Yes
TChoverCool
Analog value, 29
Cooling if lower
changeover
temperature
°C
Yes
TChover
Heat
Analog value, 30
Heating if higher
changeover
temperature
°C
Yes
RTHyst
Analog value, 31
Room temperature
hysteresis
°C
Yes
CmfDBand
Analog value, 32
Dead band for comfort
mode
°C
Yes
CmfSp
Analog value, 33
Basic setpoint for the
controller
°C
Yes
TSuSpCalc
Analog value, 34
Calculated supply air
setpoint
°C
No
Binary inputs
Object
name
Object ID
Description
Values
Writeable
RWndSta
Binary input, 0
Room window state
Active /
inactive
No
Not used
Binary input, 1
-
-
No
RPscDet
Binary input, 2
Room presence
detection
Active /
inactive
No
HCChover
Binary input, 3
Indicates changeover
from digital input
Active /
inactive
No
Not used
Binary input, 4-6
-
-
No
Binary values
Object
name
Object ID
Description
Values
Writeable
Not used
Binary value, 0
-
-
No
Outputtype
Binary value, 1
Indicates pulse prop.
heating
Active /
inactive
No
Outputtype
Binary value, 2
Indicates pulse prop.
cooling
Active /
inactive
No
3-posInc
Binary value, 3
Indicates heating
increase
Active /
inactive
No
3-posDec
Binary value, 4
Indicates heating
decrease
Active /
inactive
No
FanType
Binary value, 5
Select fan type:
Inactive = 3-speed fan
Active = DC fan
Active /
inactive
Yes
Not used
Binary value, 6
-
-
-
