Time synchronization via bus (RDG2..KN)
Time of day and date information are received from a Synco controller with time
manager function (RMB, OWZ, etc) or any other KNX device e.g. GPS clock, if
the corresponding communication object is bound.
The scheduler function must be enabled before setting the time of day:
● Press once and then turn the rotary knob or press continuously to select
programming mode TIME.
● Press once and then turn the rotary knob to select the time format.
● If 12H is selected, press once and then turn the rotary knob to select AM or
PM.
● Press once and enter the hour setting.
● The hour value flashes and can be changed by turning the rotary knob.
● Press once to confirm the adjusted value and enter the minutes setting.
Repeat the steps as for the hour.
● AM/PM does not display when set to 24 hour clock.
● Power reserve clock for 20 h during power failure (RDG2..T)
