4.6.8.2 Manager/subordinate communication in LTE-Mode
The manager thermostat shares the configuration with its subordinates for the
following:
● Room temperature and humidity value
● Operating mode
● Manual fan speed
● Current room setpoint and ChangeOverWaterStatus
If any of the above values is changed on the manager, the change is synchronized
to all subordinates within the same zone. For M/S - manager / subordinate
configuration, see M/S, Manager/subordinate configuration in LTE-Mode [➙ 123].
After initial power-on, without changes on the HMI, synchronization between
manager and subordinate may take up to 15 min.
Every change on the manager HMI, e.g. setpoint, op. mode, etc, is immediately
sent and updated on the subordinate.
A heartbeat function communicates between manager and subordinate objects.
The function ensures that information is synchronized and correct between
manager and subordinates. See Send heartbeat and receive timeout [➙ 126].
4.6.8.3 Manager/subordinate communication in KNX S-Mode
The manager thermostat shares the following values with the subordinate:
● Room temperature and humidity value
● Operating mode
● Manual fan speed
● Current room setpoint and ChangeOverWaterStatus
If any one of the above values changes on the manager, the changes are
synchronized to all units within the group. See M/S, Manager/subordinate
configuration in KNX S-Mode [➙ 118].
● Users change operating mode, comfort setpoint, control sequence, and manual
fan speed on the manager thermostat. The data is then transmitted to the
subordinates.
● The changes are synchronized to all subordinates.
