RUGGEDCOM RS910
Installation Guide
Chapter 2
Installing the Device
5
Installing the Device
The following sections describe how to install the device, including mounting the device, installing/removing
modules, connecting power, and connecting the device to the network.
DANGER!
Electrocution hazard – risk of serious personal injury and/or damage to equipment. Before performing
any maintenance tasks, make sure all power to the device has been disconnected and wait
approximately two minutes for any remaining energy to dissipate.
WARNING!
Radiation hazard – risk of serious personal injury. This product contains a laser system and is classified
as a Class I LASER PRODUCT. Use of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous radiation exposure.
IMPORTANT!
This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall
render all warranties null and void.
Changes or modifications not expressly approved by Siemens Canada Ltd could invalidate
specifications, test results, and agency approvals, and void the user's authority to operate the
equipment.
IMPORTANT!
This product should be installed in a restricted access location where access can only be gained by
authorized personnel who have been informed of the restrictions and any precautions that must be
taken. Access must only be possible through the use of a tool, lock and key, or other means of security,
and controlled by the authority responsible for the location.
The general procedure for installing the device is as follows:
1. Mount the device to a DIN rail or panel.
2. Connect power to the device and ground the device to safety Earth.
3. Connect the failsafe alarm relay.
4. Connect the device to the network.
CONTENTS
• Section2.1, “Required Tools and Materials”
• Section2.2, “Mounting the Device”
• Section2.3, “Connecting Power”
• Section2.4, “Connecting the Failsafe Alarm Relay”
• Section2.5, “Connecting to the Device”
