Chapter 4
Technical Specifications
RUGGEDCOM RS910
Installation Guide
22 Copper Ethernet Port Specifications
Section4.3
Copper Ethernet Port Specifications
The following details the specifications for copper Ethernet ports that can be ordered with the RUGGEDCOM
RS910.
Speed
c
Connector Duplex
c
Cable Type
d
Wiring
Standard
e
Maximum
Distance
f
Isolation
g
10/100Base-TX DB9 FDX/HDX > CAT 5 TIA/EIA T568A/B 100 m (328 ft) 1.5 kV
10/100Base-TX RJ-45 FDX/HDX > CAT 5 TIA/EIA T568A/B 100 m (328 ft) 1.5 kV
c
Auto-negotiating.
d
Shielded or unshielded.
e
Auto-crossover and auto-polarity.
f
Typical distance. Dependent on the number of connectors and splices.
g
RMS 1 minute.
Section4.4
Fiber Optic Ethernet Port Specifications
The following details the specifications for fiber Ethernet ports that can be ordered with the RUGGEDCOM RS910.
NOTE
• All optical power numbers are listed as dBm averages. To convert from average to peak add 3 dBm.
To convert from peak to average, subtract 3 dBm.
• Maximum segment length is greatly dependent on factors such as fiber quality, and the number
of patches and splices. Consult a Siemens sales associate when determining maximum segment
distances.
10Base-FL Fiber Optic
Mode
Connector
Type
Tx λ (nm)
h
Cable
Type (µm)
Tx min
(dBm)
Tx max
(dBm)
Rx
Sensitivity
(dBm)
Rx
Saturation
(dBm)
Distance
(km)
h
Power
Budget
(dB)
62.5/125 -16 -9 18
MM ST
50/125
850
-19.8 -12.8
-34 -11.2 2
14.2
h
Typical.
100Base-FX Fiber Optic
Tx (dBm)
Mode
Connector
Type
Tx λ (nm)
i
Cable
Type (μm)
Minimum Maximum
Rx
Sensitivity
(dBm)
Rx
Saturation
(dBm)
Distance
(km)
i
Power
Budget
(dB)
MM MTRJ 1300
50/125 -22.5 -14 -33.5 -14 2 11
