Chapter 6
Certification
RUGGEDCOM RS910
Installation Guide
32 EMC and Environmental Type Tests
Test Description Test Levels Severity Levels
1000 A/m for 1 s
Voltage Dips and Interrupts DC Power Ports 30% for 0.1 s
60% for 0.1 s
100% for 0.05 s
IEC 61000-4-29
IEC 61000-4-11 Voltage Dips
and Interrupts
100% for 5 Periods
100% for 50 Periods
Signal Ports 2.5 kV Common Mode @ 1 MHz
1 kV Differential Mode @ 1 MHz
3
DC Power Ports 2.5 kV Common Mode @ 1 MHz
1 kV Differential Mode @ 1 MHz
3
IEC 61000-4-12 Damped Oscillatory
AC Power Ports 2.5 kV Common Mode @ 1 MHz
1 kV Differential Mode @ 1 MHz
3
Signal Ports 30 V Continuous
300 V for 1 s
4IEC 61000-4-16 Mains Frequency Voltage
DC Power Ports 30 V Continuous
300 V for 1 s
4
IEC 61000-4-17 Ripple on DC Power Supply DC Power Ports 10% 3
Signal Ports 2 kV (Failsafe Relay Output)
DC Power Ports 1.5 kV
Dielectric Strength
AC Power Ports 2 kV
Signal Ports 5 kV (Failsafe Relay Output)
DC Power Ports 5 kV
IEC 60255-5
HV Impulse
AC Power Ports 5 kV
EMC Immunity Type Tests per IEEE 1613
NOTE
The RUGGEDCOM RS910 meets Class 2 requirements for an all-fiber configuration and Class 1
requirements for copper ports. Class 1 allows for temporary communication loss, while Class 2 requires
error-free and interrupted communications.
Description Test Levels
Enclosure Contact ± 8 kVESD
Enclosure Air ± 15 kV
Radiated RFI Enclosure Ports 35 V/m
Signal Ports ± 4 kV @ 2.5 kHz
DC Power Ports ± 4 kV
AC Power Ports ± 4 kV
Fast Transient
Earth Ground Ports ± 4 kV
