1. Introduction
The signs for Danger and Caution are used in this User Manual under the following
conditions:
Danger This symbol is used where there may be a danger to staff if the instructions are
disregarded or not strictly observed!
G
Caution This symbol is used where there may be damage to equipment or data if the
instructions are disregarded or not strictly observed!
Caution This symbol is used if precautionary measures must be taken in handling
electrostatically sensitive components.
F
Note This symbol is used to draw your special attention to a remark.
ð
Reference This symbol refers to additional information in other Manuals, chapters or sections.
abc¹
.
Footnote Footnotes are comments, referring to specific parts of the text. They consist of 2
parts:
1) The markings in the text are arranged as continuous superscript numbers
2) The footnote text is placed at the bottom of the page and starts with a number
and a period
٭
Action This symbol indicates that a required action is described.
The individual steps are indicated by an asterisk, e.g.:
٭ Press the
= button
PGM
Buttons
Buttons are shown in a box. Either symbols or text are possible. If a button has multiple
assignments, the text shown is always the one that corresponds to the function
currently used.
EXIT
+ =
Button
combi-
nations
The representation of buttons combined with a plus sign means that, first, the
EXIT
button must be kept depressed before pressing the other button.
1.3 Typographical conventions
1.3.1 Warning symbols
1.3.2 Notification symbols
1.3.3 Presentation
