8/57 CC1B7865en 05.12.2002 HVAC Products
2. Type of unit
The type field is glued onto the housing. The type designation consists of operating
voltage and type reference of the unit.
Type of unit Description
RWF40.000A97
RWF40.010A97 ¹·
Basic version with floating output
RWF40.001A97
RWF40.011A97 ¹·
With additional analog output
RWF40.002B97
RWF40.012B97 ¹·
With additional analog output and
RS-485 interface
¹· Packaging variants
G
The power supply must agree with the operating voltage given on the type field.
The measured value range and the analog inputs are factory-set.
ð Chapter 8 «Configuration»
Adapter frame ARG40 for plants where the RWF32... predecessor model was used (for
conversion to RWF40...).
Bracket ARG41 for mounting the RWF40... on 35 mm DIN rails conforming to
DIN 46277.
Dummy cover AVA10.200/109 for covering control panel cutouts for the RWF40...
2.1 Type field
Location
Types
Factory setting
Accessories
