Configuration Using Web Based Management and the Command Line Interface
6.3 Interfaces Menu
C79000-G8976-C184-07
141
interface.
With the menu command Interfaces > WLAN1…2 > Virtual AP count in the Access
ode, you can also configure up to eight virtual access points (VAP0 …
s interface.
Introduction
The SCALANCE W78x has one Ethernet interface and up to two WLAN interfaces
that can be configured separately. In the pages of this menu, you can configure
both the wired Ethernet interface and the WLAN
Point m
VAP7) per wireles
Note
VAPs are visible only after an AP count > 0.
6.3.1 Ethernet Menu Command
Transmission Speed and Mode
thernet connection. When you select the
entry Auto in the Speed / Mode list box, the SCALANCE W78x sets a suitable
n the other network nodes and crosses over the
ings on the partner device.
For a wired Ethernet interface, you only to specify the transmission speed / mode
parameters and the crossing over of the E
speed and mode depending o
Ethernet connection.
If you select an entry other than Auto in the Speed / Mode list box, you must
specify the crossing over of the Ethernet connection manually with Ethernet
crossing.
Note
If you specify the mode, you must make the same sett
Operating Instructions SCALANCE W78x
