Page #16 background imageLoading...
Page #16 background image
Description of the device
2.4 Spare parts
SCALANCE XM-400
16 Operating Instructions, 05/2014, C79000-G8976-C306-03
2.4
Spare parts
The following spare parts are available for SCALANCE XM-400:
Component
Description
Order number
C-PLUG Configuration plug,
exchangeable storage medium for configuration data
6GK1 900-0AB00
Spring-loaded terminal block,
4 terminals
4-terminal spring-loaded terminal block to connect the
power supply (24 VDC),
for SCALANCE X/W/S/M,
pack of 5
6GK5 980-1DB10-0AA5
Spring-loaded terminal block,
2 terminals
2-terminal spring-loaded terminal block to connect the
signaling contact (24 VDC),
for SCALANCE X/W/S/M,
pack of 5
6GK5 980-0BB10-0AA5
Securing screw Screw for mounting on an S7-1500 and S7-300 standard
rail,
for SCALANCE X/W,
pack of 5
6GK5 980-4AA00-0AA5
Connecting cable
(RJ-11/RS-232)
preassembled, serial cable with RJ-11 and RS-323 plug,
Length: 5 m
pack of 1
6GK5 980-3BB00-0AA5
