Connecting up
4.5 Serial interface
SCALANCE XM-400
52 Operating Instructions, 05/2014, C79000-G8976-C306-03
Note
Pin assignment of the RJ-11 jack on the device
The RJ
-11 jack on the device has a pinout to match the RJ-11 plug of the supplied
connecting cable.
