VRRP
Entry-ID: 109798556, V1.0, 09/2021
© Siemens AG
2021 All rights reserved
Assigning the IP address
The first assignment of an IP address for the SCALANCE cannot be done with
Web Based Management, because this configuration tool requires an IP address in
the first place.
There are several ways to assign an IP address to an unconfigured device:
• SINEC PNI
• PRONETA
• STEP 7
• DHCP
SINEC PNI and PRONETA are available to you for free as downloads in the
Industry Online Support.
Assign the planned IP address to the two SCALANCE routers with one of the
aforementioned tools:
Table 3-2
VRRPv3 supports IPv4 and IPv6. Both can be configured and operated
simultaneously with VRRPv3.
The following figures describe configuration with SINEC PNI.
1. Click "Start network scan".
2. Select the device found.
3. Click the "Device Management" button.
