Siemens SCALANCE XR-500 User Manual

Protocol Protocol/
Port number
Default port
status
Con󹪝gurable Authenti‐
cation
Encryption
6)
Port Service
DHCPv6 Client (IPv6) UDP/546 Closed - ✓ - -
EtherNet/IP
2)
TCP/44818
UDP/2222
UDP/44818
Closed - ✓ - -
HTTP Server/Client
4)
TCP/80 Closed ✓ ✓ ✓ -
HTTPS WBM Server/Client TCP/443 Open ✓ ✓ ✓ ✓
MSDP TCP/639 Closed -- ✓ - -
NTP Client UDP/123 Closed ✓ ✓ - -
NTP (secure) UDP/123 Closed ✓ ✓ ✓ -
PROFINET UDP/34964
UDP/49151 ...
49159
1)
Open -- ✓ - -
RADIUS Client UDP/1812
5)
UDP/1813
5)
Outbound only ✓ ✓ - -
UDP/3799 Open ✓ ✓ - -
RIP UDP/520 Closed - ✓ - -
RIPng IPv6 UDP/521 Closed - ✓ - -
SFTP Server UDP/22 Outbound only ✓ ✓ ✓ ✓
SMTP Client TCP/25 Closed ✓ ✓ -- --
SMTP Client (secure) TCP/465 Closed ✓ ✓ ✓ ✓
SNMPv1/v2c
3) 4)
UDP/161 Open ✓ ✓ - -
SNMPv3 UDP/161 Open ✓ ✓ Optional Optional
SNMP Traps UDP/162 Outbound only -- ✓ - -
SNTP Client UDP/123 Closed ✓ ✓ - -
SSH CLI Server TCP/22 Open ✓ ✓ ✓ ✓
Syslog Client UDP/514 Closed ✓ ✓ - -
Syslog (secure) Client TCP/6514 Closed ✓ ✓ - -
Telnet
4)
TCP/23 Closed ✓ ✓ ✓ -
TFTP Client UDP/69 Outbound only ✓ ✓ - -
VRRP TCP/50000 Open, 󹪝ltered -- ✓ - -
1) Port number can be con󹪝gured via the WBM.
2) Service disabled by default.
3) Read-only access only.
4) Protocol according to Security by Default.
5) The port is closed by default and is displayed when a RADIUS server is con󹪝gured. Port number can be con󹪝gured via the WBM.
6) You can 󹪝nd additional information on the encryption methods used in the WBM appendix "Ciphers used".
The following is a list of all available Layer 2 services through which the device can be
accessed.
Security recommendations
3.1Security recommendations
SCALANCE XR-500
Operating Instructions, 07/2023, C79000-G8976-C692-01 21
